What's in the box
1a
1c
1d
1b
19
14
17
ITEM NO.
1
EMPower Unit
1a
Smart Module
1b
Battery Cover
1c
AA Batteries
1d
M4-0.7 x 8mm Machine Screws
1e
Interior Escutcheon
1f
#10-32 x 2-1/8" Machine
Screws
1g
Mounting Plate
2
Interior Knob/Lever Assembly
3
#8-32 x 1-1/2" Machine Screws
4
Deadbolt Latch 2-3/4" Backset
4
Deadbolt Latch 2-3/8" Backset
5
Deadbolt Screw Guide
6
Deadbolt Trim
1f
1g
2
1e
18
16
20
DESCRIPTION
3
11
21
QTY.
ITEM NO.
1
7
8
1
9
1
4
10
11
3
12
1
13
2
14
1
15
1
16
2
17
1
18
1
19
1
20
1
21
5
4
1
14
9
10
14
13
12
DESCRIPTION
Deadbolt Extension Collar
Deadbolt Cylinder
Passage Latch
Latch Face Plate
Decorative Cap
#8-32 Flat head Machine Screw
Threaded Washer
#8 x 3/4" Wood Screws
Sectional Entry Set Assembly
Latch Strike Plate
Deadbolt Strike Plate
Deadbolt Security Plate
#10 x 3" Wood Screws
Connect Wi-Fi Bridge
DoorSense
TM
6
8
7
15
QTY.
1
1
1
1
1
1
1
8
1
1
1
1
2
1
1
Advertisement
Table of Contents
Need help?
Do you have a question about the Adams Handleset EMPowered EMP4414FRKUS10B-2 and is the answer not in the manual?
Questions and answers
How do I remove this? I am changing doors..
To remove the Emtek Adams Handleset EMP4414FRKUS10B-2, follow these general steps based on the installation reverse process:
1. Remove Battery Cover: Loosen the screw on the bottom of the interior escutcheon to remove the battery cover.
2. Remove Interior Escutcheon: Ensure the bolt is in the retracted (unlocked) position, then unscrew and remove the interior escutcheon.
3. Remove Interior Mounting Plate: Unscrew the mounting plate and carefully disconnect any wiring if applicable.
4. Remove Lock Cylinder: Detach the lock cylinder by removing screws and the extension collar if used.
5. Remove Grip and Interior Lever/Knob: Unscrew and detach the handle components from both sides of the door.
6. Remove Deadbolt Latch and Strike Plates: Unscrew the deadbolt latch from the door edge and remove the strike plates from the door jamb.
Reverse the installation steps using appropriate tools, and handle components carefully to avoid damage.
This answer is automatically generated
