Maximum tightening torque for mounting and accessories: 15Nm.
Mounting direction:
The screws must not
come into contact with
the white silicone.
S9 sensor:
Maximum tightening torque for mounting and accessories:
For load cells up to 10kN: 50Nm (M12)
•
For 20kN load cells: 200Nm (M24x2)
•
•
For 50kN load cells: 500Nm (M24x2)
Mounting direction:
- 8 -
Instruction manual
CENTOR EASY II
Strain gauge zone
