- Page 1 EOS Majesty Heater for Sauna Cabins Installation and Operating Instructions...
-
Page 2: Documentation
Result of a step Table title Title of figure ≤ ≥ Less than or equal to, greater than or equal to Revision history Date Version Description 1 Nov. 2022 01.00 First version EN-2 Installation and Operating Instructions - EOS Majesty... -
Page 3: Table Of Contents
Establishing an electrical connection ..........EN-26 Heating time limitation............... EN-26 5 Commissioning ....................EN-27 Filling rock stores with stones ............EN-27 Starting the heater................EN-28 Commissioning by remote control..........EN-29 Water splash.................... EN-29 EOS Majesty - Installation and Operating Instructions EN-3... - Page 4 Sauna stones ................... EN-31 Changing the electrical connection ..........EN-32 Replacing the tubular heating elements ........EN-35 Troubleshooting ..................EN-39 7 General terms and conditions of service ........... EN-40 8 Disposal ......................EN-43 EN-4 Installation and Operating Instructions - EOS Majesty...
-
Page 5: General Safety Instructions
The sauna heater may not be placed on a floor made of easily flammable material (e.g. laminate or synthetic flooring). Ceram- ic tiles are recommended as a flooring option. EOS Majesty - Installation and Operating Instructions EN-5... - Page 6 This control unit is fixed to a suitable location on the cabin's external wall, and the corresponding sensor housings according to the installation instructions that accom- pany the control units inside the sauna cabin. EN-6 Installation and Operating Instructions - EOS Majesty...
-
Page 7: Operator Instruction
Spending time in a sauna cabin can lead to serious health risks or even death for persons with health impairments. Persons with health impairments who spend time in a sauna must consult a doctor before entering a sauna cabin. EOS Majesty - Installation and Operating Instructions EN-7... - Page 8 Children and persons who have not received proper instruction must not clean or service the system. EN-8 Installation and Operating Instructions - EOS Majesty...
-
Page 9: Safety Levels
For an overview of the standards that were observed during design and construction of the sauna heaters, please refer to the individual product’s technical data sheet that can be downloaded from www.eos-sauna.com. Local regulations also apply to the installation and operation of heating, sauna, and steam room systems. -
Page 10: Identification
Identification Identification EOS Majesty is an electrically heated sauna heater for Finnish mode availa- ble in a variety of output capacities. Requirements for operation The heater must be operated with one of the following control units: Econ series EmoTec series ... -
Page 11: Scope Of Delivery
50–100 mm, approx. 15 kg C Sauna stones made of quartz, white, approx. 10 kg Accessories (optional) Accessories (optional) Item number EOS heater guard rail (to protect unit from being 94.6972 touched)* Distributor for 1-phase connection 94.2689 Guard rail, abachi wood, with bracket 94.8052... -
Page 12: Technical Data
All line cross-section specifications are the minimum cross-sections for the copper line. The sauna heater must be operated by a sauna control unit. *) Only for the EOS Econ, EmoTec, EmoStyle, and EmoTouch control units. EN-12 Installation and Operating Instructions - EOS Majesty... -
Page 13: Intended Use
This heater is intended solely for the purpose of heating sauna cabins, together with a suitable control unit. EOS Majesty is suitable for commercial and private use. The heater is not suitable for outdoor use. It must be operated only inside buildings and may not be exposed to envi-... - Page 14 The first time the cabin is heated, you may notice a slight odour result- ing from the evaporation of consumables used in the manufacturing processes. Air out your cabin once it has been heated and before using the sauna. EN-14 Installation and Operating Instructions - EOS Majesty...
-
Page 15: Installation
All lines must be routed in such a way that they are well-protected, e.g. in a cable duct. EOS recommends laying all connecting cables through a bendable metal tube connected to the protective conductor. EOS Majesty - Installation and Operating Instructions... -
Page 16: Installation Site
8 cm 37 cm 5 cm 8 cm 42 cm 5 cm A Cabin ceiling D Heater B Cabin wall E Air inlet C Heater guard rail Dimensions in the cabin EN-16 Installation and Operating Instructions - EOS Majesty... -
Page 17: Air Inlets And Outlets
Heater is located in front of the cabin wall: air inlet from the side A Air inlet B Heater Supply air from below (figure on the left) and from the side (figure on the right) EOS Majesty - Installation and Operating Instructions EN-17... -
Page 18: Temperature Sensor
A heater guard rail may be placed around the upper edge of the heater. It prevents accidental contact with hot parts of the heater. You can purchase a suitable heater guard rail from the sauna heater manu- facturer. See Accessories (optional), EN-11 EN-18 Installation and Operating Instructions - EOS Majesty... -
Page 19: Installing The Heater
Do not place the heater too close to a wall prior to commissioning. It must still be possible to reach the terminal box at the rear of the heat- Lift the heater from the pallet and move it to the pre-defined installation site. EOS Majesty - Installation and Operating Instructions EN-19... -
Page 20: Connecting Cable
Drilling template for concealed connecting cable Lay the connecting cable along the heater base from the cabin to the con- trol unit or power extension unit. A Rear of heater C Connecting cable B Cable feed opening EN-20 Installation and Operating Instructions - EOS Majesty... -
Page 21: Electrical Installation
The sauna control unit and the heater must be connected as shown in the circuit diagrams. Please observe the installation and operating instructions for the sauna control unit. See also 2.4 Technical data, EN-12. EOS Majesty - Installation and Operating Instructions EN-21... -
Page 22: Connecting To 400 V 3N
A Sauna control unit C Heater B Safety temperature limiter D Mains connection for sauna control unit Connection diagram 6, 8 and 10* kW *) Only for connecting to EOS Compact control units. EN-22 Installation and Operating Instructions - EOS Majesty... - Page 23 D Mains connection for sauna control B Safety temperature limiter unit C Heater E Power extension unit (LSG) 10 kW* connection diagram *) Only for connecting with EOS Econ, EmoTec, EmoStyle, and EmoTouch control units. EOS Majesty - Installation and Operating Instructions EN-23...
-
Page 24: Connecting To 230 V 1N
* Cable cross-sections must correspond to the sauna heater output: 6 kW – 4 mm² 8 kW – 6 mm² A distributor for the 1-phase connection can be purchased separately: Item no. 94.2689 EN-24 Installation and Operating Instructions - EOS Majesty... -
Page 25: Internal Wiring
6, 8 and 10 kW heater output ) r G Internal wiring 6, 8 and 10 kW 6 kW = 6x 1000 W 8 kW = 6x 1333 W 10 kW = 6x 1666 W EOS Majesty - Installation and Operating Instructions EN-25... -
Page 26: Establishing An Electrical Connection
6 consecutive hours within a 24-hour period. Units used in private saunas must be limited to an operating time of 6 hours, and an automatic restart is not permitted. EN-26 Installation and Operating Instructions - EOS Majesty... -
Page 27: Commissioning
This leads to over- heating of the heater. Start the heater only if it has been filled with stones. Place the stones loosely. EOS Majesty - Installation and Operating Instructions EN-27... -
Page 28: Starting The Heater
Switching the system on Switch the sauna control unit on. The heater is switched on via the control unit. Use the control unit to select a suitable program. EN-28 Installation and Operating Instructions - EOS Majesty... -
Page 29: Commissioning By Remote Control
After each water splash, wait approx. 10 minutes before starting the next one. This time is needed for the sauna stones to reheat. Recommendation: During a water splash, no more than approx. 10 cL of water per m³ cabin volume should be vaporised. EOS Majesty - Installation and Operating Instructions EN-29... -
Page 30: Maintenance
Switch off the heater from the control unit. Wait until the heater is completely cool. Clean the outside of the heater. Use only household cleaning agents. Remove lint and dust from openings and heat reflectors. EN-30 Installation and Operating Instructions - EOS Majesty... -
Page 31: Sauna Stones
Remove the stone if damaged and replace it with a new one. Rinse all stones with cold water. Place the stones loosely so that there is enough space between them for air to circulate sufficiently. Filling the rock store, EN-28 EOS Majesty - Installation and Operating Instructions EN-31... -
Page 32: Changing The Electrical Connection
If necessary, pull the heater away from the wall if the rear of the heater cannot be reached. Push the lock on the left and right under the back panel of the sauna heater upwards. This opens the screw lock. EN-32 Installation and Operating Instructions - EOS Majesty... - Page 33 Push the back panel upwards as far as it will go and then pull it forward out of the sauna heater. Loosen the screws on the covers of the terminal box and remove the covers. EOS Majesty - Installation and Operating Instructions EN-33...
- Page 34 Connect the connecting cable to the control unit or the power extension unit and the control unit. Observe the regulations of the local power supply company (EVU) and the Association for Electrical, Electronic & Information Technolo- gies (VDE). EN-34 Installation and Operating Instructions - EOS Majesty...
-
Page 35: Replacing The Tubular Heating Elements
Replacing the tubular heating elements, EN-37 Inserting the heating coil, EN-38 Hardware and tools: Tubular heating element or heating coil Screwdriver Hexagon key Ring or socket spanner EOS Majesty - Installation and Operating Instructions EN-35... - Page 36 Opening the terminal box, EN-32 Loosen the connecting cable from the connection terminals. Unscrew the 6 hexagon socket screws on the heating coil. Pull out the terminal box with the heating coil. EN-36 Installation and Operating Instructions - EOS Majesty...
- Page 37 Fix the heating element with the serrated washers and the fixing nuts. Plug in the flat plug. Check the wiring on all heating elements before reclosing the termi- nal box and setting up the heater. EOS Majesty - Installation and Operating Instructions EN-37...
- Page 38 Put on the covers of the terminal box and the rear panel of the heater. Closing the housing, EN-35 Move the heater back into its original position. Place the stones in the rock store. Switch on the fuses of the heater. EN-38 Installation and Operating Instructions - EOS Majesty...
-
Page 39: Troubleshooting
The position of the temperature sensor Check the position of the temperature in the cabin is not optimal. sensor and adjust as needed. See 3.1.3 Temperature sensor, EN-18. EOS Majesty - Installation and Operating Instructions EN-39... -
Page 40: General Terms And Conditions Of Service
The customer shall provide assistance free of charge to the manufacturer in rendering services. In the case of a warranty claim, the manufacturer shall provide spare parts necessary for servicing free of charge. EN-40 Installation and Operating Instructions - EOS Majesty... - Page 41 Electrical assembly and installation work, including service visits and parts replacements, shall be carried out at the customer‘s expense; costs shall not be borne by the manufacturer. EOS Majesty - Installation and Operating Instructions EN-41...
- Page 42 Complaints in respect of our products shall be reported to the responsible distributor and shall be handled exclusively by said distributor. The manufacturer’s General Terms and Conditions of Business, in the ver- sion available at www.eos-sauna.com/agb, shall apply in addition to the foregoing terms and conditions of service. EN-42...
-
Page 43: Disposal
The following materials are used in the packaging: Used paper/cardboard Plastic foil Electronic waste Electronic waste must be disposed of at the designated local collection point for electronic waste. EOS Majesty - Installation and Operating Instructions EN-43... - Page 44 made in Germany Stand 50/2022 Druck-Nr. 2902 5175 All rights reserved.
