- Page 1 Appliance dedicated to the Australian market Applicable standard: AS 4563- 2004 (Commercial Catering Gas Equipment) Professional gas griddle plate Instruction for use Original instructions - 1 - AI0330 Ed.1...
-
Page 2: Take Care
Dear Customer, Thank you very much for purchasing one of our appliances. It is very easy to use however you are advised to carefully read these instructions prior to installation and first usage in order to ensure optimum results. Receipt and unpacking If any damage is caused during transportation from the freight company, the freight company must be informed in writing with acknowledgement of receipt within 24 hours of receiving the item. -
Page 3: Installation
Technical description Commercial description of appliance: GGCIC30AD (model with 1 burner) and GGCIC40AD (model with 2 burners). 3 kW PLANCHA –TECHNICAL SPECIFICATIONS (GGCIC30AD) -
Page 4: Do Not Spray Aerosols In The Vicinity Of This Appliance While It Is In Operation
Check the air tightness of the fitting with soapy water. Never test the air tightness with a flame. This appliance is supplied with a Bromic BM-WFIA-NG B-0-20-HT (AGA5149) regulator for Natural Gas or a Maxitrol RV48 (AGA3088) Regulator for LPG (Propane). Please test operation of the appliance after installation and inform the operator/s on using it safely. - Page 5 4. Press the piezo (red ignition button) then push in the knob in this position until the burner is fully ignited. 5. Keep the knob pressed in between 5 and 10 seconds to trip the thermocouple safety system. 6. Release the knob and allow the burner to heat the hot plate to the suitable temperature. If the burner does not light, wait a minute to allow gas to dissipate and then repeat from step 3.
-
Page 6: Maintenance And Cleaning
6. Put back the knob adhering to the orientation of the flat surface on the shaft of the tap. Spark plug of piezo To ensure correct ignition of the burner, the plug must always be positioned at 5 mm from the burner (see figure 5). - Page 7 FIGURE 1 – BOTTOM VIEW FIGURE 2 – VENTURY OPENING Protection 1 or 5 mm See page 3 for the adjustement value of the ventury. Undo screws to remove bottom cover. FIGURE 3 – BURNER VIEW FIGURE 4 – IDLE ADJUSTEMENT Burner locking screw FIGURE 5 –...
- Page 8 Krampouz SAS - Z.A. Bel Air - 29700 Pluguffan - France - Tel. +33 (0)2.98.53.92.92 - Fax. +33 (0)2.98.53.92.93 www.krampouz.com – contact@krampouz.com - 8 -...
