Owner's Instruction and Operation Manual
Model Number:
US3200E
Report Number: F20-586
Tested Per EPA Methods ALT-125, ASTM
E2515, ASTM E3053 and CSA B415
Certified to UL 1482-2022, CAN/ULC
S627:2023
Approved for Mobile Home/Transportable
Building installation
* All Pictures In This Manual Are For Illustrative Purposes Only. Actual Product May Vary.
Save These Instructions In A Safe Place For Future Reference.
SAFETY NOTICE: If this heater is not properly installed, a house fire may result. For
your safety, follow the installation instructions. Never use make-shift compromises
during the installation of this heater. Contact local building or fire officials about
permits, restrictions and installation requirements in your area. NEVER OPERATE
THIS PRODUCT WHILE UNATTENDED.
CAUTION! Please read this entire manual before you install or use your new room
heater. Failure to follow instructions may result in property damage, bodily injury, or
even death. Improper Installation Will Void Your Warranty!
U.S. Environmental Protection Agency
Certified to comply with 2020 particulate
emissions standards.
THIS MANUAL IS SUBJECT TO CHANGE WITHOUT NOTICE.
© 2023 United States Stove Company, 227 Industrial Park Rd., South Pittsburg, TN 37380
R
CALIFORNIA PROPOSITION 65 WARNING:
This product can expose you to chemicals including carbon
monoxide, which is known to the State of California to cause
cancer, birth defects, and/or other reproductive harm. For
more information, go to www.P65warnings.ca.gov
853742G-0606M
Ph. 800-750-2723
Advertisement
Table of Contents
Related Manuals for United States Stove Company US3200E
Summary of Contents for United States Stove Company US3200E
- Page 1 State of California to cause emissions standards. cancer, birth defects, and/or other reproductive harm. For more information, go to www.P65warnings.ca.gov THIS MANUAL IS SUBJECT TO CHANGE WITHOUT NOTICE. © 2023 United States Stove Company, 227 Industrial Park Rd., South Pittsburg, TN 37380 Ph. 800-750-2723...
- Page 2 The instructions pertaining to the installation of your wood stove comply with UL 1482-2022 and CAN/ULC S627:2023 standards. This manual describes the installation and operation of the USSC, US3200E wood heater. This heater meets the 2020 U.S. Environmental Protection Agency’s cordwood emission limits for wood heaters sold after May 15, 2020.
-
Page 3: Installation Checklist
Declaration of Completion: As the qualified person responsible for the work described above, I confirm that the appliance as associated work has been installed as per manufacturer’s instructions and following any applicable building and installation codes. Signed: ______________________________________ Print Name: __________________________________Date: ______________ Home Owner: RETAIN THIS INFORMATION FOR FUTURE REFERENCE © 2023 United States Stove Company... -
Page 4: Blower Assembly
ASH PAN The ash pan is located below the firebox. 3. Slide the U-shaped skirting assembly around the pedestal base and secure with two 1/4” long pan head sheet metal screws at the rear corners. © 2023 United States Stove Company... -
Page 5: Installation
A wood stove must never be installed in a hallway or near a staircase, since it may block the way in case of fire or fail to respect required clearances. © 2023 United States Stove Company... -
Page 6: Floor Protector
4. The house is equipped with a well-sealed vapor • To reduce flue clearances from combustible materials, barrier and tight fitting windows and/or has any contact your local safety department. powered devices that exhaust house air. © 2023 United States Stove Company... -
Page 7: Chimney Connector (Stove Pipe)
Furthermore, the installation of a draft damper is not recommended. With a controlled combustion wood stove, the draft is regulated upon intake of the combustion air in the stove and not at the exhaust. © 2023 United States Stove Company... -
Page 8: Importance Of Proper Draft
The following recommendations may be useful for the installation of your chimney: It must rise above the roof at least 3’ (0.9m) from the When a metal prefabricated chimney is used, the uppermost point of contact. manufacturer’s installation instructions must © 2023 United States Stove Company... -
Page 9: Masonry Chimney
To Stove Floor Protector Airtight Cleanout Door COMBUSTIBLE WALL CHIMNEY CONNECTOR PASS-THROUGHS METHOD A - 12” (305 mm) Clearance to Combustible Wall Member: Using a minimum thickness 3.5” (89 mm) © 2023 United States Stove Company... - Page 10 1” (25.4 mm) or more, and an inside diameter or ceiling. of 8” (2 inches [51 mm] larger than the 6” [153 mm] © 2023 United States Stove Company...
- Page 11 Smaller pieces of wood will dry faster. All logs exceeding FIBERBOARD, OR INSULATION REMOVED. 6” in diameter should be split. The wood should not be stored directly on the ground. Air should circulate through © 2023 United States Stove Company...
-
Page 12: Testing Your Wood
TAMPER WARNING FUELING INSTRUCTIONS This wood heater has a manufacturer-set minimum low burn rate that must not be altered. It is against federal This wood stove has been certified by the US EPA © 2023 United States Stove Company... - Page 13 For a medium burn, once the high burn fuel load is SPECIFICATIONS CAN RESULT IN PERMANENT burned down to an established coal bed, load the unit with DAMAGE TO THE HEATER. 31 to 32 lbs of cordwood and keep the door slightly open © 2023 United States Stove Company...
-
Page 14: Air Tubes
The blower should be removed at the beginning of every highest efficiency. Any damage or deterioration of these “burn” season and air-blown clean, removing any dust or tubes may reduce the efficiency of combustion. The air build-up. © 2023 United States Stove Company... -
Page 15: Chimney Maintenance
While the modern combustion systems in operating temperatures. The secondary combustion heaters drastically reduce the amount of CO emitted can only take place if the firebox is hot enough. out the chimney, exposure to the gases in closed or © 2023 United States Stove Company... -
Page 16: Glass Care
Part numbers and descriptions can be found in the “Repair Parts” section of this manual. Once this information has been gathered you can contact customer service by phone 1-800-750-2723 Ext 5051 or Email parts@ usstove.com. Model Information Model Number Serial Number © 2023 United States Stove Company... -
Page 17: Wiring Diagram
DO NOT INSTALL IN AN ALCOVE non-combustible pad that will provide ember protection. DO NOT INSTALL IN ANY FIREPLACE The 450 mm (18 in) ember protection required on any © 2023 United States Stove Company... -
Page 18: Repair Parts
Email to: parts@usstove.com IN ORDER TO MAINTAIN WARRANTY, COMPONENTS MUST BE REPLACED USING ORIGINAL MANUFACTURERS PARTS PURCHASED THROUGH YOUR DEALER OR DIRECTLY FROM THE APPLIANCE MANUFACTURER. USE OF THIRD PARTY COMPONENTS WILL VOID THE WARRANTY. © 2023 United States Stove Company... - Page 19 Email to: parts@usstove.com IN ORDER TO MAINTAIN WARRANTY, COMPONENTS MUST BE REPLACED USING ORIGINAL MANUFACTURERS PARTS PURCHASED THROUGH YOUR DEALER OR DIRECTLY FROM THE APPLIANCE MANUFACTURER. USE OF THIRD PARTY COMPONENTS WILL VOID THE WARRANTY. © 2023 United States Stove Company...
-
Page 20: Service Record
Engineer Name: ____________________________________ Engineer Name: ____________________________________ License No.: ________________________________________ License No.: ________________________________________ Company: __________________________________________ Company: __________________________________________ Telephone No.: _____________________________________ Telephone No.: _____________________________________ Stove Inspected: Chimney Swept: Stove Inspected: Chimney Swept: Items Replaced: ____________________________________ Items Replaced: ____________________________________ © 2023 United States Stove Company...
