Owner's Instruction and Operation Manual
Model Number:
KP60
Report #: F20-571
Certified to ASTM E1509-12 (2017)
and Certified to ULC-S627-00-REV1
Mobile Home Approved
* All Pictures In This Manual Are For Illustrative Purposes Only. Actual Product May Vary.
Save These Instructions In A Safe Place For Future Reference.
SAFETY NOTICE: If this heater is not properly installed, a house fire may result. For
your safety, follow the installation instructions. Never use make-shift compromises
during the installation of this heater. Contact local building or fire officials about
permits, restrictions and installation requirements in your area. NEVER OPERATE
THIS PRODUCT WHILE UNATTENDED.
CAUTION! Please read this entire manual before you install or use your new room
heater. Failure to follow instructions may result in property damage, bodily injury, or
even death. Improper Installation Will Void Your Warranty!
U.S. Environmental Protection Agency
Certified to comply with 2020 particulate
emissions standards.
THIS MANUAL IS SUBJECT TO CHANGE WITHOUT NOTICE.
© 2021 United States Stove Company, 227 Industrial Park Rd., South Pittsburg, TN 37380
R
CALIFORNIA PROPOSITION 65 WARNING:
This product can expose you to chemicals including carbon
monoxide, which is known to the State of California to cause
cancer, birth defects, and/or other reproductive harm. For
more information, go to www.P65warnings.ca.gov
853243J-0204K
Ph. 800-750-2723
Advertisement
Table of Contents
Related Manuals for United States Stove Company KP60
Summary of Contents for United States Stove Company KP60
- Page 1 State of California to cause emissions standards. cancer, birth defects, and/or other reproductive harm. For more information, go to www.P65warnings.ca.gov THIS MANUAL IS SUBJECT TO CHANGE WITHOUT NOTICE. © 2021 United States Stove Company, 227 Industrial Park Rd., South Pittsburg, TN 37380 Ph. 800-750-2723...
- Page 2 Your stove is Certified to ASTM E1509-12 (2017) and Certified. This manual describes the installation and operation of the USSC, KP60 pellet stove. This heater meets the 2020 U.S. Environmental Protection Agency’s crib wood emission limits for wood-heaters sold after May 15, 2020. Under specific EPA test conditions burning Douglas Fir dimensional lumber this heater has been shown to deliver heat at a rate of 8,476 to 20,700 Btu/hr.
-
Page 3: Installation Checklist
Declaration of Completion: As the qualified person responsible for the work described above, I confirm that the appliance as associated work has been installed as per manufacturer’s instructions and following any applicable building and installation codes. Signed: ______________________________________ Print Name: __________________________________Date: ______________ Home Owner: RETAIN THIS INFORMATION FOR FUTURE REFERENCE © 2021 United States Stove Company... -
Page 4: Installation
CORD IN FOOT TRAFFIC AREAS OR PINCH THE CORD UNDER FURNITURE. US Stove highly recommends your stove be installed by a qualified NFI (US) or WETT (Canada) technician. To find the nearest qualified installer, go to: https://nficertified.org, https://www.wettinc.ca/ © 2021 United States Stove Company... -
Page 5: Installation Options
J Ceiling Height To Appliance 27” 686 mm CLEARANCES Your pellet stove has been tested and listed for installation in residential, mobile home in accordance with the clearances given below. For safety reasons, please adhere © 2021 United States Stove Company... -
Page 6: Outside Air Supply
Installation MUST include at least 3-feet of vertical pipe following requirements: outside the home. This will create some natural draft to reduce the possibility of smoke or odor during appliance • This stove must be securely fastened to the floor of © 2021 United States Stove Company... -
Page 7: Pellet Vent Termination
Hi-Temp RTV silicone sealant to be airtight. The area where the vent pipe penetrates to the exterior of C. Minimum 3-foot (0.91m) clearance from any the home must be sealed with silicone or other means to adjacent building. © 2021 United States Stove Company... -
Page 8: Through The Wall Installation
10. Push the unit straight back to the interior wall, structure, a 3” (76 mm) clearance should be maintained being sure to maintain the minimum clearances to from the outside wall and a clean out tee should be © 2021 United States Stove Company... -
Page 9: Through The Roof/Ceiling Installation
• Do not exceed more than 4ft (1.22m) of pipe on a horizontal run and use as few elbows as possible. If an offset is required, it is better to install 45-degree elbows rather than 90-degree elbows. © 2021 United States Stove Company... - Page 10 If this situation continues, the fuel in the burn pot © 2021 United States Stove Company...
-
Page 11: Control Panel Overview
See the list of button is pressed. The fan will automatically adjust its error codes found at the end of this manual. speed in accordance to the heat range setting. However, © 2021 United States Stove Company... -
Page 12: Thermostat Hook-Up
T’Stat requires more heat, the unit will begin to feed pellets at the preselected heat setting ranging from “1” to “5”. Use 18 gauge, 2 conductor wire © 2021 United States Stove Company... -
Page 13: Proper Fuel
INTO AN ELECTRICAL OUTLET. THESE MOVING Your pellet stove is designed to burn premium hardwood PARTS MAY BEGIN TO MOVE AT ANY TIME pellets that comply with the Pellet Fuels Institute (PFI) WHILE THE STOVE IS PLUGGED IN. © 2021 United States Stove Company... -
Page 14: Optimal Operation
If the stove shuts down push flashing “E3” the “On/Off” button to re-start your stove. The stove will © 2021 United States Stove Company... -
Page 15: Shutdown Procedure
Some regular vacuum cleaner thermodisc. This unit has a manual reset thermodisc. (i.e. shop vacs) may leak ash into the room. This safety switch has two functions. DO NOT VACUUM HOT ASH. © 2021 United States Stove Company... -
Page 16: Maintenance
CHECK & CLEAN THE HOPPER be removed with a brush specifically designed for the Check the hopper periodically to determine if there is any type of chimney in use. A qualified chimney sweep can © 2021 United States Stove Company... -
Page 17: Spring Shutdown
5. Re-install the retainer and eight nuts and rope gasket Gaskets Inspected using high-temperature silicone to adhere the gasket Glass Wiped Cleaned to the door. Hopper (end of Empty & 6. Never use substitute materials for the glass. season) Vacuumed © 2021 United States Stove Company... -
Page 18: Troubleshooting Guide
ATTENTION: THIS WOOD HEATER NEEDS PERIODIC INSPECTION AND REPAIR FOR PROPER OPERATION. IT IS AGAINST FEDERAL REGULATIONS TO OPERATE THIS WOOD HEATER IN A MANNER INCONSISTENT WITH OPERATING INSTRUCTIONS IN THIS MANUAL. © 2021 United States Stove Company... -
Page 19: Display Indicators
FACTORY DEFAULTS To return the control to its original factory default settings, press and hold the AUX UP and AUX DOWN buttons together for three seconds. © 2021 United States Stove Company... -
Page 20: Repair Parts
REPAIR PARTS © 2021 United States Stove Company... - Page 21 Call 1-800-750-2723 Ext 5051 or Email to: parts@usstove.com IN ORDER TO MAINTAIN WARRANTY, COMPONENTS MUST BE REPLACED USING USSC PARTS PURCHASED THROUGH YOUR DEALER OR DIRECTLY FROM USSC. USE OF THIRD PARTY COMPONENTS WILL VOID THE WARRANTY. © 2021 United States Stove Company...
-
Page 22: Wiring Diagram
Part numbers and descriptions can be found in the “Repair Parts” section of this manual. Once this information has been gathered you can contact customer service by phone 1-800-750-2723 Ext 5051 or Email parts@usstove.com. Model Information Model Number Serial Number © 2021 United States Stove Company... -
Page 23: Service Record
Engineer Name: ____________________________________ Engineer Name: ____________________________________ License No.: ________________________________________ License No.: ________________________________________ Company: __________________________________________ Company: __________________________________________ Telephone No.: _____________________________________ Telephone No.: _____________________________________ Stove Inspected: Chimney Swept: Stove Inspected: Chimney Swept: Items Replaced: ____________________________________ Items Replaced: ____________________________________ © 2021 United States Stove Company... - Page 24 NOTES © 2021 United States Stove Company...
- Page 26 BLANC NOIR BLANC ROUGE BLEU ORANGE...
