Owner's Operation and Instruction Manual
King Pellet Stove
THIS MANUAL WILL HELP YOU TO OBTAIN EFFICIENT, DEPENDABLE SERVICE FROM THE HEATER, AND ENABLE YOU
TO ORDER REPAIR PARTS CORRECTLY. KEEP IN A SAFE PLACE FOR FUTURE REFERENCE.
• Please read this entire manual before installation and use of this
appliance. Failure to follow these instructions could result in property
damage, bodily injury, or even death.
• Contact your local building or fire officials about obtaining permits,
restrictions and installation inspection requirements in your area.
• Save these instructions.
Ce produit peut vous exposer à des produits chimiques, y compris le
• If your heater is not properly installed, a house fire may result. For
monoxyde de carbone, qui est connu dans l'État de Californie pour causer
everyone's safety, follow all Installation and Operating Directions.
Never use makeshift compromises during the installation of this
le cancer, des malformations congénitales et / ou d'autres problèmes de
appliance. Contact your local building or fire officials about
reproduction. Pour plus d'informations, visitez www.P65warnings.ca.gov
restrictions and installation inspection requirements in your area.
CALIFORNIA PROPOSITION 65 WARNING:
This product can expose you to chemicals including carbon monoxide, which
is known to the State of California to cause cancer, birth defects and/or other
reproductive harm. For more information, go to www.P65warnings.ca.gov
MODEL: KP130
SAVE THESE INSTRUCTIONS
United States Stove Company
227 Industrial Park Road
South Pittsburg, TN 37380
Report #: 215-S-05c-2
Certified to ASTM E 1509, 2012, and Certified to
ULC S627, 2000, and(UM) 84-HUD
This unit is not intended to be used as a
primary source of heat.
U.S. Environmental Protection Agency
Certified to comply with 2015 particulate
emissions standards.
853143B-2603H
Advertisement
Table of Contents
Related Manuals for United States Stove Company King Pellet Stove KP130
Summary of Contents for United States Stove Company King Pellet Stove KP130
- Page 1 State of California to cause cancer, birth defects and/or other U.S. Environmental Protection Agency Certified to comply with 2015 particulate reproductive harm. For more information, go to www.P65warnings.ca.gov emissions standards. United States Stove Company 227 Industrial Park Road 853143B-2603H South Pittsburg, TN 37380...
-
Page 2: Safety Precautions
Safety Precautions This manual describes the installation and operation of the pellet stove. King, KP130 • IMPORTANT: Read this entire manual before installing • The exhaust system should be checked monthly and operating this product. Failure to do so may result during the burning season for any build-up of soot or in property damage, bodily injury, or even death. -
Page 3: Specifications
Specifications HEATING SPECIFICATIONS Fuel Burn Rate* 1.5 - 5.0 lbs./hr. (0.7 - 2.3 kg/hr) Burn Time (lowest setting) 80 hrs. Hopper Capacity 130lbs. (59kg) * Pellet size may effect the actual rate of fuel feed and burn times. Fuel feed rates may vary by as much as 20%. Use PFI listed fuel for best results. -
Page 4: Installation Options
Installation INSTALLATION OPTIONS Read this entire manual before you install and use your pellet stove. Failure to follow instructions may result in property damage, bodily injury, or even death! (See specific installation details for clearances and other installation requirements) A Freestanding Unit—supported by pedestal/legs and placed on a non-combustible floor surface in compliance with clearance requirements for a freestanding stove installation. - Page 5 Installation CLEARANCES Your pellet stove has been tested and listed for installation in residential, mobile home, and alcove applications in accordance with the clearances given in TABLE 1. NOTE: Distance “B” on the side of your pellet stove may need to be greater than the minimum required clearance for suitable access to the control panel.
-
Page 6: Venting Requirements
Installation VENTING REQUIREMENTS • INSTALL VENT AT CLEARANCES SPECIFIED BY THE VENT MANUFACTURER. • DO NOT CONNECT THE PELLET VENT TO A VENT SERVING ANY OTHER APPLIANCE OR STOVE. • DO NOT INSTALL A FLUE DAMPER IN THE EXHAUST VENTING SYSTEM OF THIS UNIT. The following installation guidelines must be followed to ensure conformity with both the safety listing of this stove and to local building codes. -
Page 7: Vent Termination Clearances
Installation VENT TERMINATION CLEARANCES A. Minimum 4-foot (1.22m) clearance below or beside any door or window that opens. B. Minimum 1-foot (0.3m) clearance above any door or window that opens. C. Minimum 3-foot (0.91m) clearance from any adjacent building. D. Minimum 7-foot (2.13m) clearance from any grade when adjacent to public walkways. E. -
Page 8: Through The Wall Installation
Installation THROUGH THE WALL INSTALLATION (RECOMMENDED INSTALLATION) Canadian installations must conform to CAN/CSA-B365. To vent the unit through the wall, connect the pipe adapter to the exhaust motor adapter. If the exhaust adapter is at least 18 in.(457mm) above ground level, a straight section of pellet vent pipe can be used through the wall. -
Page 9: Outside Air Supply
Installation OUTSIDE AIR SUPPLY (OPTIONAL, UNLESS INSTALLING IN A MOBILE HOME) Depending on your location and home construction, outside air may be necessary for optimal performance. Metal pipe (solid or flexible) must be used for the outside air installation. PVC pipe is NOT approved and should NEVER be used. -
Page 10: Understanding Your Stove
Indicator & Button with an automatic ignition system & Button that should ignite the fuel within 5-10 DESCRIPTION HOLES GENERAL NOTES: © 2010 United States Stove Company TOLERANCES .005" ALL RIGHTS RESERVED minutes from pressing the ON button. EXCEPT ALL FORMED DIMENSIONS ARE TO THE DATA CONTAINED HEREIN IS PROPRIETARY TO U. -
Page 11: Control Panel Overview
Control Panel Overview Turning the heater ON/OFF, as well as adjustments for the fuel feed rate and room fan speed are performed by pressing the appropriate button(s) on the control panel which is located on the lower left-hand side of your heater. -
Page 12: Thermostat Hook-Up
Thermostat Hook-Up Must Remove Jumper First Put female plug fittings on the lead wires to your low voltage thermostat. Plug one thermostat lead onto each of the terminal posts on the circuit board. The stove will now drop back to heat setting 1. -
Page 13: Operation
Operation UNIT PREPARATION After carefully unpacking and reading the instructions for installing your stove, you will need to perform the following steps: • Attach the included spring handle to the door handle by screwing it on in a respective location. •... -
Page 14: Shutdown Procedure
This heater is designed to burn only PFI Premium grade pellets. DO NOT BURN: 1. Garbage; 10. Salt water driftwood or other previously salt water 2. Lawn clippings or yard waste; saturated materials; 3. Materials containing rubber, including tires; 11. Unseasoned wood; or 4. -
Page 15: Maintenance
1. If the stove is still warm, it will resume feeding fuel and continue to operate normally. If the fire has gone out, you will have to press the “OFF” button and then the “ON” button again to begin a new start-up sequence. 2. -
Page 16: Chimney Connector
ASH DISPOSAL Disposal of ashes – Ashes should be placed in a steel container with a tight fitting lid and moved outdoors immediately. The closed container of ashes should be placed on a non-combustible floor or on the ground, well away from combustible materials, pending final disposal. -
Page 17: Troubleshooting
Trouble Shooting • Disconnect the power cord before performing any maintenance! NOTE: Turning the ON/OFF Switch to ”OFF” does not disconnect all power to the electrical components of the stove. • Never try to repair or replace any part of the stove unless instructions for doing so are given in this manual. All other work should be done by a trained technician. -
Page 18: Display Indicators
DISPLAY INDICATORS Several situations or events are indicated in normal operation by blinking display indicators or segments in the display: Flashing On Indicator: This means that the stove is in the “Start Up” state waiting for the ignition procedure to complete. -
Page 19: Wiring Diagram
Wiring Diagram -19-... -
Page 20: Parts List
Parts List Part No. Description Qty. 89586 Nipple 69524 Feed Door Assembly 891121 Silicone Hose 3” 891372 Door Hinge Pad 83537 Hose Clamp (#4) 25080B Feed Door Latch 88119 Insulation Blanket 69693 Burnpot Housing Weldment 88168 Burnpot Housing Gasket 86624 Burnpot Assembly 26096MB Hearth 25513... -
Page 21: Parts Diagram
Parts Diagram -21-... -
Page 22: Service Provider
Service Record It is recommended that your heating system is serviced regularly and that the appropriate Service Interval Record is completed. SERVICE PROVIDER Before completing the appropriate Service Record below, please ensure you have carried out the service as described in the manufacturer’s instructions. Always use the manufacturer's specified spare part when replacement is necessary. - Page 23 • Repair or replacement of parts that are subject to normal wear and tear during The warrantor of record is United States Stove Company, PO Box 151, 227 the warranty period. These parts include: paint, pellet, and the discoloration Industrial Park Road, South Pittsburg, Tennessee 37380. Phone number: (800)- of glass.
- Page 24 2. The part description / La description de la pièce 3. The model number / Le numéro de modèle 4. The serial number / Le numéro de série United States Stove Company 227 Industrial Park Road P.O. Box 151 South Pittsburg, TN 37380 (800) 750-2723 WWW.USSTOVE.COM...
