Vehicle connections

The connection information listed below is specific to the 2019 Hyundai Santa Fe. Refer to "Pre-installation and application warnings" for a list of important notes.
Data harness, 8-pin white connector (H1)
Module
Conn./Pin Color Description
H1/1 Tan (Data) HS CAN Low 1
H1/2 Tan/Black (Data) HS CAN High 1
H1/3 Orange/Brown (Data) HS CAN Low 2
H1/4 Orange/Green (Data) HS CAN High 2
H1/5 Lt. Green No Connection
H1/6 Violet/Brown (MUX) Pk Light Output
H1/7 Orange/Black
(Data) Immo. Data (conn.side)
H1/8 Yellow/Black No Connection
Analog input/output harness, 22-pin white connector (H2)
Module
Conn./Pin Color Description
H2/1 Lt. Green/Black
(-) Ignition Interrupt Output
H2/2 Blue/White (-) Ground When Running (Status) Output
H2/3 Dk. Green/Black (-) Lock Output
H2/4 Red/White (-) Trunk Release Output
H2/5 Brown/Black (-) Horn Output
H2/6 Brown/White (-) AUX 1 Output
H2/7 White (+) AUX 1 Output
H2/8 Violet/Black (+) AUX 2 Output
H2/9 Dk. Blue/Black (-) Unlock Output
H2/10 Lt. Blue/Black (-) Factory Alarm Disarm Output
H2/11 Brown/Red
(+) Siren Output
H2/12 Pink (+) Ignition Sense Input
H2/13 Violet (+) Door Trigger Input
H2/14 Brown (+) Brake Input
H2/15 White/Blue (-) Activation Input
H2/16 Red/Blue No Connection
H2/17 Black/White (-) E-Brake Input
9 933.HK18 1.18.198.12 2019 Hyundai Santa Fe
©2023 Directed. All rights
Connects To
Wire Location
ICU Junction Block-Dash Fuse Box, rear, black 32 pin plug (F), pin 23
ICU Junction Block-Dash Fuse Box, rear, black 32 pin plug (F), pin 22
ICU Junction Block-Dash Fuse Box, rear, black 32 pin plug (F), pin 31
ICU Junction Block-Dash Fuse Box, rear, black 32 pin plug (F), pin 32
No Connection
Headlight-Wiper Switch, black 16 pin plug, pin 14
[4] Driver Kick, red 54 pin plug (EM11), pin 40
The EMS COM connection is NOT required in US vehicles without
transponder.
No Connection
Connects To
Wire Location
[5] Must use a relay.
5A fuse to 12V.
ICU Junction Block-Dash Fuse Box, rear, white 47 pin plug (G), pin 1
Only applicable when using a T-Harness
No Connection
No Connection
No Connection
Horn Switch-Clock Spring, white 14 pin plug, pin 8 --or-- Driver Kick,
red 54 pin plug (EM11), pin 4
No Connection
No Connection
No Connection
No Connection
No Connection
[2] The siren is ONLY required when enabling the security features during
module flashing.
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
(+/-) Wire Color Connection
Data Gray (P-CAN) Mandatory
Data White (P-CAN) Mandatory
Data Blue (B-CAN) Mandatory
Data Red (B-CAN) Mandatory
MUX Yellow Mandatory
Data White/Orange or Black Remote Start
Only
(+/-) Wire Color Connection
Cut Gray/Orange Remote Start
Only
- White/Black Optional
Security Only
