INSTALLATION / OWNER'S GUIDE
RVMDVR
REV: 0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VOXXADAS RVMDVR and is the answer not in the manual?

Questions and answers

Summary of Contents for Voxx Electronics VOXXADAS RVMDVR

  • Page 1 INSTALLATION / OWNER’S GUIDE RVMDVR REV: 0...
  • Page 2 Your first priority while driving should always be the safe operation of your vehicle. VOXX Electronics Corporation cannot accept any responsibility whatsoever for accidents resulting from failure to observe these precautions or safety instructions.
  • Page 3: Installation

    Installation System Layout Front Camera (Orange) Constant 12-Volt (+) Input - Yellow Optional Rear Camera (Black) Acc. 12-Volt (+) Input - RED Ground (-) Input - Black...
  • Page 4 Installation Mirror Installation (Universal Wedge Mount) Windshield 1. Remove the original mirror and prepare RVMDVR for installation • Inspect all parts of the RVMDVR to ensure no defects are present before installation. • Using a Phillips screw driver, loosen mounting set screw. 2.
  • Page 5: User Interface

    Introduction User Interface The screen shown above is available at any time when the display is active. 1. Event / Snapshot: Press and release to take a picture; Press and hold to trigger event lock. 2. Display View: Toggle between camera views. 3.
  • Page 6: Basic Features And Functions

    Introduction Basic Features and Functions Video Recording: The system will automatically begin to record when the vehicle’ s ignition is turned ON. The system will continuously record until the vehicle’ s ignition is turned OFF. The system will record video files until the memory card storage is full. Once the card is full the system will begin to overwrite the oldest video files to create available storage files.
  • Page 7: Menu Options

    Main Menu Menu Options Menu options are available at any time by pressing the Settings (Gear) icon from the main screen. Note: All recording functions will stop while configuring settings. 滚滚长江东逝水 Storage: View the remaining SD card storage space; Format SD card. Resolution: Set recoding resolution.
  • Page 8 Main Menu Menu Options Date and Time: Set the date and time settings including time zone and daylight savings mode. Display Mode: Set the display to be ON at all times or automatically shutdown. Brightness Setting: Set the brightness level. Volume: Set the volume level for menu beep confirmation and file playback.
  • Page 9 Main Menu Menu Options • Rear Flip: Set the display mode for the rear camera. Setting to ON will flip the image vertically. • Rear Cam Mirror: Set the display of the rear camera. Setting to ON will mirror the image horizontally.
  • Page 10: Features Settings

    Features Settings Feature Descriptions Storage Capacity : The system includes a 32GB Micro SD card. The SD card slot is located on the bottom of the mirror. The system is compatible with up to 256GB SD card. It is recommended to format the SD card the first time it is used and every 3-4 months.
  • Page 11: 12 Month Limited Warranty

    Warranty 12 Month Limited Warranty VOXX Electronics Corporation (the Company) warrants to the original purchaser of this product that should this product or any part thereof, under normal use and conditions, be proven defective in material or workmanship within 12 months from the date of original purchase, such defect(s) will be repaired or replaced with new or reconditioned product, (at the Company’s option) without charge for parts or repair labor.
  • Page 12 ©2024 VOXX Electronics Corp., 2351 J. Lawson Blvd. Orlando, FL 32824...
