Wiring diagram with T-Harness (THHYN3 Rev. 2)
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
Ignition Switch
31 26 17
ICU Junction
Block Plug (G)
45
(white conn. rear
of fuse box)
40 24 15
41 25 16
31
Immo. Data:
White/Orange
or Black, pin 40
40
2 22 45
1 12 34 44
EM11
(red conn. in
driver kick panel)
6 933.HK18 1.18.198.12 2019 Hyundai Santa Fe
©2023 Directed. All rights
(optional T-Harness)
1A Diode (1N4002+)
87
Fuse 5A
(+) 12V
87a
86 85
30
Ign. Interr.:
Cut
Gray/Orange,
pin 1
1
Acc. Interr.:
Pink, pin 45
Cut
Cut
ICU Junction Block Plug (F)
(black conn. rear of fuse box)
1 2 3 4 5 6 7 8 9 10 11 12 13
17 18 19 20 21 22 23 24 25 26 27 28 29
P-CAN High: P-CAN Low:
White, pin 22 Gray, pin 23
THHYN3 Rev. 2
(-) Ignition Interrupt Output: Lt. Green/Black
Accessory Interr. (conn. side): Lt. Green
Accessory Interr. (veh. side): Lt. Green/White
Headlight-Wiper Switch
(black conn. at
1 2 3 4 5 6 7 8
headlight switch)
9 10 11 12 13 14 15 16
(MUX) Parking Lights:
Yellow, pin 14 (MUX) Parking Light Output: Violet/Brown
(+) Siren Output: Brown/Red
Siren
Hood Pin
Immo. Data (conn. side): Orange/Black
Immo. Data Interrupt (conn. side): Blue
Immo. Data Interrupt (veh. side): Blue/White
B-CAN Low: Blue, pin 31
B-CAN High: Red, pin 32
14 15 16
Cut the Tan and
30 31 32 Tan/Black OBD CAN LOOPS
before connecting the
t-harness to the vehicle.
Diagnostic
Connector
OBDII
(-) Hood Input: Gray
HS CAN Low 2: Orange/Brown
HS CAN High 2: Orange/Green
HS CAN Low 1: Tan
HS CAN High 1: Tan/Black
Cut the
Yellow/Black loop
for this installation.
).
IMPORTANT:
Position the
fuses correctly!
Slide to open
Legend:
Mandatory Connections
Security Only
Remote Start Only
Remote Start + Security
