Voxx Electronics DIRECTWIRE DIRECTECHS DS3 Installation Manual page 11

Module
Conn./Pin Color Description
H3/12 Red (+) 12 Volt Input
Relay harness, 10-pin white connector (H4)
Module
Conn./Pin Color Description
H4/1 N/A No Connection
H4/2 Red/Black (+) 12 Volt Input
H4/3 Pink/Black Flex Relay (pin 87a)
H4/4 Pink/White (+) Flex Relay Output
H4/5 Red (+) 12 Volt Input
H4/6 Green
Starter Input (conn. side)
H4/7 Violet (+) Starter Output (vehicle side)
H4/8 Orange (+) Accessory Output
H4/9 Red/White (+) 12 Volt Input
H4/10 Pink (+) Ignition Input/Output
RF Port harness, 2-pin white connector (H5)
Module
Conn./Pin
H5/1
H5/2
D2D harness, 4-pin white (1) and black (2) connectors (H6)
Module
Conn./Pin
H6/1
H6/2
H6/3
H6/4
Temperature sensor harness, 2-pin black connector (H7)
Module
Conn./Pin Color Description
H7/1 Black Temperature Sensor
11 933.HK18 1.18.198.12 2019 Hyundai Santa Fe
©2023 Directed. All rights
Connects To
Wire Location
Ignition Switch, black 6 pin plug, pins 1 and 5
Connects To
Wire Location
No Connection
Ignition Switch, black 6 pin plug, pins 1 and 5
No Connection
No Connection
Ignition Switch, black 6 pin plug, pins 1 and 5
[3] Ignition Switch, black 6 pin plug, pin 3
Connection required for Starter Disable ONLY.
Ignition Switch, black 6 pin plug, pin 3
Ignition Switch, black 6 pin plug, pin 2
No Connection
Ignition Switch, black 6 pin plug, pin 4
Color
N/A
N/A
Color
Blue
Black
Green
Red
Connects To
Wire Location
(+/-) Wire Color
+ Blue/Orange and White
(15A)
(+/-) Wire Color
+ Blue/Orange and White
(15A)
+ Blue/Orange and White
(15A)
+ Black (with IMMO); Pink
(w/o IMMO)
+ Black (with IMMO); Pink
(w/o IMMO)
+ Blue
+ Green
Description
RF Loop
RF Loop
Description
(Data) TX
(-) Ground
(Data) RX
(+) 12 Volt
(+/-) Wire Color
Connection
Mandatory
Connection
Remote Start
Only
Remote Start
Only
Mandatory
Mandatory
Remote Start
Only
Mandatory
Connection
