Voxx Electronics VOXX DEI DS3+ Installation Manual

Hide thumbs Also See for VOXX DEI DS3+:
Table of Contents

Advertisement

Quick Links

Download this manual
Functions compatible with the 2008 Toyota FJ Cruiser
*Telematics features: The telematics features listed below (with an asterisk) ONLY apply when using SmartStart Pro.
* Odometer
Accessory Activation
Arm Factory Security
Disarm Factory Security
Door Lock Control
Door Unlock
DS4+/DS3+/VSM3 Only
Entry Monitoring ALL Door Pins
Entry Monitoring Hood Pin
Entry Monitoring Trunk/Hatch Pin
Fuel level/EV battery level
Ignition Activation
Immobilizer Bypass-Data No Key Req'd
Parking Lights Control
Remote Start Takeover
SmartStart
Start (Crank) Activation
Tach / RPM Output
Trunk / Hatch Release
933.TL11
v1.16.198.12
2008 Toyota FJ Cruiser
THTON10 Compatible
(Sold Separately)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VOXX DEI DS3+ and is the answer not in the manual?

Questions and answers

Related Manuals for Voxx Electronics VOXX DEI DS3+

Summary of Contents for Voxx Electronics VOXX DEI DS3+

  • Page 1 933.TL11 v1.16.198.12 2008 Toyota FJ Cruiser THTON10 Compatible (Sold Separately) Functions compatible with the 2008 Toyota FJ Cruiser *Telematics features: The telematics features listed below (with an asterisk) ONLY apply when using SmartStart Pro. * Odometer Fuel level/EV battery level Accessory Activation Ignition Activation Arm Factory Security...

  • Page 2: Table Of Contents

    Contents Introduction Pre-installation and application warnings Installation Wiring diagram with T-Harness (THTON10) Wiring diagram Locating components in the vehicle Vehicle connections Module programming (For security-only programming, see next section.) Module programming for security-only installations Pairing remotes Connecting the module 8556T Temperature Sensor 8504D Combo Sensor RF Systems When used in conjunction with SmartStart...

  • Page 3: Introduction

    Introduction This guide provides information on the installation of the DS3/DS3+ and DS4/DS4+ modules as a digital solution. Using these modules in a digital configuration requires the module to be flashed with vehicle-specific firmware. Refer to our website (www.directechs.com) and click on the DIRECTLINK text in the header for additional information.

  • Page 4: Pre-Installation And Application Warnings

    Pre-installation and application warnings This section highlights important information for this specific firmware and will assist in pricing accordingly, as START HERE well as bringing awareness to any operational or vehicle limitations. Compatibilities and Requirements T-Harness Keys required for Keys required THTON10 programming for operation...
  • Page 5 Wiring diagram with T-Harness (THTON10) Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( Transponder Key Amplifier Ignition Connector Diagnostic Connector OBDII (black conn. around ignition) THTON10 (optional T-Harness) Cut the Tan and Tan/Black loops.

  • Page 6: Wiring Diagram

    Wiring diagram Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( Transponder Key Amplifier (black conn. around ignition) Refer to ‘Vehicle Connections ’ for more information on vehicle-specific wiring connections.

  • Page 7: Locating Components In The Vehicle

    Locating components in the vehicle 933.TL11 1.16.198.12 2008 Toyota FJ Cruiser ©2023 Directed. All rights...

  • Page 8: Vehicle Connections

    Vehicle connections The connection information listed below is specific to the 2008 Toyota FJ Cruiser. Refer to “Pre-installation and application warnings” for a list of important notes. Data harness, 8-pin white connector (H1) Module Connects To Conn./Pin Color Description Wire Location (+/-) Wire Color Connection...
  • Page 9 Module Connects To Conn./Pin Color Description Wire Location (+/-) Wire Color Connection H2/19 Blue (-) Trunk Input No Connection H2/20 Green dash fuse box, white 20 pin plug (1A), pin 8 white Security Only (-) Door Input H2/21 Gray Not Applicable (-) Hood Switch Input The installation of an aftermarket hood pin is only required on vehicles that are not equipped with a factory hood pin or if not supported in...
  • Page 10 Module Connects To Conn./Pin Color Description Wire Location (+/-) Wire Color Connection H4/8 Orange (+) Accessory Output ignition switch, white 8 pin plug, pin 3 white/green Remote Start Only H4/9 Red/White (+) 12 Volt Input ignition switch, white 8 pin plug, pin 7 blue/black (30A) Remote Start Only...

  • Page 11: Module Programming

    Module programming Refer to “LED diagnostics and troubleshooting” for more information and for troubleshooting purposes. (For security-only programming, see next section.) With transponder without CAN Please ensure that the vehicle is in a safe location, and cannot move forward during programming.

  • Page 12: Module Programming For Security-Only Installations

    Module programming for security-only installations Refer to "LED diagnostics and troubleshooting" for more information and for troubleshooting purposes. Ensure vehicle is in a safe location and cannot move forward during programming. For vehicles equipped with a manual transmission, make sure the gearshift is in the neutral position. Connect the 12-pin main power harness to the module.

  • Page 13: Pairing Remotes

    Pairing Remotes and Sensors To enter pairing: Key OUT Key IN Key IN Key IN Turn the vehicle ignition to the ON position. START START START START Within 10 seconds, on the Control Center (antenna) or the LED/Valet Pod (standalone switch), press and release once (1x), and then press and hold &...

  • Page 14: When Used In Conjunction With Smartstart

    before providing power to the Directed SmartStart unit: ® SmartStart with Loops – The brown loop must be cut. SmartStart with Pigtails – The gray wire must be connected to a ground source. Loops Pigtails DO NOT connect the Directed SmartStart 2-pin power harness when using the DS3+/DS4+.

  • Page 15: Manual Transmission

    Manual Transmission IMPORTANT! Directed does not approve nor support installations of manual transmission and remote starts on any electronic vehicles (EV), OEM Remote Start Activation firmware, vehicles with convertibles and/or removable tops, including but not limited to Jeep Wrangler, Honda S2000, Mazda Miata, and other such vehicles. This system supports manual transmission installations.

  • Page 16: Led Diagnostics And Troubleshooting

    LED diagnostics and troubleshooting This section provides LED diagnostics and troubleshooting information to guide you through the various stages of your installation. Module Programming Description Troubleshooting Make sure the D2D harness is connected and that 12 Volt is present between the red and black wires. If Module has no power.
  • Page 17   External Module Synchronization Description Troubleshooting OBDII feature not supported. The diagnostic data bus was not detected, therefore the SmartStart features will be limited. (Flashes red, red, then orange) x 10 Active Ground When Running (Status) Description Troubleshooting Ground When Running (Status) command The module has initialized the remote start sequence.

  • Page 18: Soft Reset

    Soft reset A module reset will only erase the steps perfomed in “Module Programming”. The firmware and settings flashed to the module will not be affected. Connect all but the If required for your installation, connect all the harnesses to the module, EXCEPT the 12-pin main 12-pin harness power harness.

  • Page 19: Tach Learning Procedure (Not Needed With Virtual Tach)

    Tach learning procedure (not needed with Virtual Tach) Data Tach: The procedure is not required as the tach comes preprogrammed. However, it is strongly recommended to learn the exact value of the vehicle for the most consistent and reliable starting and functionality. Hardwired Tach: The procedure is required.

  • Page 20: Limited Lifetime Consumer Warranty

    Limited Lifetime Consumer Warranty VOXX DEI LLC (the Company) warrants to the original purchaser of this product that should this product or any part thereof, under normal use and conditions, be proven defective in material or work- manship within the Lifetime from the date of original purchase in the original vehicle, such defect(s) will be repaired or replaced with new or reconditioned product, (at the Company’s option) without charge for parts or repair labor.

  • Page 21: Quick Reference Guide

    Quick Reference Guide Sending commands to your vehicle Pit stop/idle mode Whether you want to remote start the engine, lock/unlock the doors or pop the trunk, Stop the vehicle in a safe parking spot and put the there are 3 possible ways you can send commands to your vehicle, using the: gear in gear in Park (P).
  • Page 22 SmartStart Bluetooth compatibility (applicable to DS4/DS4+ ONLY) This system is equipped with a Bluetooth version of SmartStart offering up to 200' of range. The simple graphical interface gives you control over the following features of your installed remote start system or security with remote start system: •...
