Voxx Electronics VOXX DEI DS3+ Installation Manual

Smart key for 2016 audi a3
Hide thumbs Also See for VOXX DEI DS3+:
Table of Contents

Advertisement

Quick Links

Download this manual
Functions compatible with the 2016 Audi A3 (Smart Key)
*Telematics features: The telematics features listed below (with an asterisk) ONLY apply when using SmartStart Pro.
* Odometer
3x LOCK START (Start control using OEM Remote)
3x LOCK STOP (Stop control using OEM Remote)
Accessory Activation
Arm Factory Security
Brake Status (foot brake)
Control of aftermarket alarm with OEM remote
Disarm Factory Security
Door Lock Control
Door Locks Status
Door Unlock
Driver Priority Unlock
E-Brake Status
Entry Monitoring ALL Door Pins
Entry Monitoring Hood Pin
Entry Monitoring Trunk/Hatch Pin
Factory Alarm Trigger Monitoring
Fuel level/EV battery level
Ignition Activation
Ignition Status
Parking Lights Control
RAP Shut Down (Retained ACC Power)
Remote Start Takeover
SmartStart
Start (Crank) Activation
Tach / RPM Output
Trunk / Hatch Release
Universal RF Bypass- Key Req'd
933.VW06
v2.02.198.12
2016 Audi A3 (Smart Key)
THVWN1 Compatible
(Sold Separately)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VOXX DEI DS3+ and is the answer not in the manual?

Questions and answers

Related Manuals for Voxx Electronics VOXX DEI DS3+

Summary of Contents for Voxx Electronics VOXX DEI DS3+

  • Page 1 933.VW06 v2.02.198.12 2016 Audi A3 (Smart Key) THVWN1 Compatible (Sold Separately) Functions compatible with the 2016 Audi A3 (Smart Key) *Telematics features: The telematics features listed below (with an asterisk) ONLY apply when using SmartStart Pro. * Odometer Entry Monitoring Hood Pin 3x LOCK START (Start control using OEM Remote) Entry Monitoring Trunk/Hatch Pin 3x LOCK STOP (Stop control using OEM Remote)

  • Page 2: Table Of Contents

    Contents Introduction Pre-installation and application warnings Installation Wiring Diagram with T-Harness (THVWN1) Wiring diagram Key Wrap options for THVWN1 Immobilizer Interface with OEM Immob. receiver Locating components in the vehicle Vehicle connections Module programming (For security-only programming, see next section.) Module programming for security-only installations Pairing remotes Connecting the module...

  • Page 3: Introduction

    Introduction This guide provides information on the installation of the DS3/DS3+ and DS4/DS4+ modules as a digital solution. Using these modules in a digital configuration requires the module to be flashed with vehicle-specific firmware. Refer to our website (www.directechs.com) and click on the DIRECTLINK text in the header for additional information.

  • Page 4: Pre-Installation And Application Warnings

    Pre-installation and application warnings Firmware notes: This section highlights important information for this specific firmware and will assist in pricing accordingly, as well as bringing awareness to any operational or vehicle limitations. T-Harness THVWN1 Keys required for Keys required for compatible programming operation...

  • Page 5: Installation

    Wiring diagram with T-Harness (THVWN1) Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( 13 38 Refer to the (-) Hazards: THVWN1 Optional starter disable Violet/Red, pin 42 connection section for relay (optional T-Harness) and connection details.

  • Page 6: Wiring Diagram

    Wiring diagram Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( Electronic Steering Column Module (black connector under column) HS CAN 1 High: (-) PTS 2: Blue/Yellow, pin 13 Orange/Red, pin 6 OBDII Diagnostic (connector side view)

  • Page 7: Key Wrap Options For Thvwn1

    Key Wrap Option 1 with T-Harness (THVWN1) Use the T-harness component labeled Key Wrap - Option 1. Wrap the loop around the OEM Immobilizer Remote and connect to the OEM Immobilizer Receiver Switch as shown below. THVWN1 (main section of T-Harness, connector side view) Key Wrap Starter Starter...

  • Page 8: Immobilizer Interface With Oem Immob. Receiver

    Immobilizer interface For vehicles with Keyless Entry you must remove battery from OEM key (the OEM remote may differ from the models shown in the illustrations). Method 1: Key Wrap N.O. Relay 2: Lt. Green/Red: 7 4-6 loops COM Relay 2: Lt. Green: 8 4-6 loops Immobilizer Remove battery from...
  • Page 9 Method 3: Key wrap using OEM Immobilizer Ring Immobilizer Immobilizer Ring N.O. Relay 2: Lt. Green/Red: 7 COM Relay 2: Lt. Green: 8 N.C. Relay 2: Lt. Green/White: 9 Remove battery from OEM Remote Control 4-6 loops Note: - Make 4-6 loops and place them around the front of the plastic body of the vehicle’s coded key as shown above. - Connect with OEM Immobilizer Ring as shown in the above diagram.

  • Page 10: Locating Components In The Vehicle

    Locating components in the vehicle VESCM - Vehicle Electrical System Control Module at Driver Side under dash, above Driver Kick Panel ESCLCM - Electronic Steering Column Lock Control Module at Steering Column 933.VW06 2.02.198.12 2016 Audi A3 (Smart Key) ©2023 Directed. All rights...
  • Page 11 Optional starter disable connection When using an external relay, use a 1N4002 diode or larger. Note: This connection is NOT REQUIRED when using a THVWN1 T-Harness. 1A diode [1N4002+] (+) Ignition (-) Ground When Armed (GWA) Output: Dk.Blue/Black: 9 Refer to the Vehicle connections section for wire and Starter (conn.

  • Page 12: Vehicle Connections

    Vehicle connections The connection information listed below is specific to the 2016 Audi A3 (Smart Key). Refer to “Pre-installation and application warnings” for a list of important notes. Data harness, 8-pin white connector (H1) Module Connects To Conn./Pin Color Description Wire Location (+/-) Wire Color...
  • Page 13 Module Connects To Conn./Pin Color Description Wire Location (+/-) Wire Color Connection H2/19 Blue No Connection No Connection H2/20 Green No Connection No Connection H2/21 Gray (-) Hood Switch Input H2/22 Violet/White No Connection No Connection Main harness, 12-pin black connector (H3) Module Connects To Conn./Pin...
  • Page 14 RF Port harness, 2-pin white connector (H5) Module Conn./Pin Color Description H5/1 RF Loop H5/2 RF Loop D2D harness, 4-pin white (1) and black (2) connectors (H6) Module Conn./Pin Color Description H6/1 Blue (Data) TX H6/2 Black (-) Ground H6/3 Green (Data) RX H6/4...

  • Page 15: Module Programming

    Module programming Refer to “LED diagnostics and troubleshooting” for more information and for troubleshooting purposes. (For security-only programming, see next section.) Please ensure that the vehicle is in a safe location, and cannot move forward during programming. For vehicles equipped with a manual transmission, make sure the gearshift lever is in the neutral position.

  • Page 16: Module Programming For Security-Only Installations

    Module programming for security-only installations Refer to "LED diagnostics and troubleshooting" for more information and for troubleshooting purposes. Ensure vehicle is in a safe location and cannot move forward during programming. For vehicles equipped with a manual transmission, make sure the gearshift is in the neutral position. Connect the 12-pin main power harness to the module.

  • Page 17: Pairing Remotes

    Pairing Remotes and Sensors To enter pairing: Key OUT Key IN Key IN Key IN Turn the vehicle ignition to the ON position. START START START START Within 10 seconds, on the Control Center (antenna) or the LED/Valet Pod (standalone switch), press and release once (1x), and then press and hold &...

  • Page 18: When Used In Conjunction With Smartstart

    before providing power to the Directed SmartStart unit: ® SmartStart with Loops – The brown loop must be cut. SmartStart with Pigtails – The gray wire must be connected to a ground source. Loops Pigtails DO NOT connect the Directed SmartStart 2-pin power harness when using the DS3+/DS4+.

  • Page 19: Manual Transmission

    Manual Transmission IMPORTANT! Directed does not approve nor support installations of manual transmission and remote starts on any electronic vehicles (EV), OEM Remote Start Activation firmware, vehicles with convertibles and/or removable tops, including but not limited to Jeep Wrangler, Honda S2000, Mazda Miata, and other such vehicles. This system supports manual transmission installations.

  • Page 20: Led Diagnostics And Troubleshooting

    LED diagnostics and troubleshooting This section provides LED diagnostics and troubleshooting information to guide you through the various stages of your installation. Module Programming Description Troubleshooting Make sure the D2D harness is connected and that 12 Volt is present between the red and black wires. If Module has no power.
  • Page 21   External Module Synchronization Description Troubleshooting OBDII feature not supported. The diagnostic data bus was not detected, therefore the SmartStart features will be limited. (Flashes red, red, then orange) x 10 Active Ground When Running (Status) Description Troubleshooting Ground When Running (Status) command The module has initialized the remote start sequence.

  • Page 22: Soft Reset

    Soft reset A module reset will only erase the steps perfomed in “Module Programming”. The firmware and settings flashed to the module will not be affected. Connect all but the If required for your installation, connect all the harnesses to the module, EXCEPT the 12-pin main 12-pin harness power harness.

  • Page 23: Tach Learning Procedure (Not Needed With Virtual Tach)

    Tach learning procedure (not needed with Virtual Tach) Data Tach: The procedure is not required as the tach comes preprogrammed. However, it is strongly recommended to learn the exact value of the vehicle for the most consistent and reliable starting and functionality. Hardwired Tach: The procedure is required.

  • Page 24: Limited Lifetime Consumer Warranty

    Limited Lifetime Consumer Warranty VOXX DEI LLC (the Company) warrants to the original purchaser of this product that should this product or any part thereof, under normal use and conditions, be proven defective in material or work- manship within the Lifetime from the date of original purchase in the original vehicle, such defect(s) will be repaired or replaced with new or reconditioned product, (at the Company’s option) without charge for parts or repair labor.

  • Page 25: Quick Reference Guide

    Quick Reference Guide Sending commands to your vehicle Pit stop/idle mode Whether you want to remote start the engine, lock/unlock the doors or pop the trunk, Stop the vehicle in a safe parking spot and put the gear in there are 3 possible ways you can send commands to your vehicle, using the: gear in Park (P).
  • Page 26 SmartStart Bluetooth compatibility (applicable to DS4/DS4+ ONLY) This system is equipped with a Bluetooth version of SmartStart offering up to 200' of range. The simple graphical interface gives you control over the following features of your installed remote start system or security with remote start system: •...
