Installing and setting up
the SMC HRS-040 chiller
This document provides information on how to install and set up the SMC HRS-040 chiller plumbing
kit.
Affected products
The following products are affected:
•
CP4440-RGB
•
CP4445-RGB
•
CP4450-RGB
•
CP4455-RGB
Required components and tools
The following components and tools are required.
Required components
•
SMC HRS-040 Chiller kit (P/N: 163-186106-XX)
•
SMC HRS-040 Chiller Assembly kit (P/N: 163-185105-XX)
•
Chiller Connection kit for CP44XX-RGB (P/N: 163-187107-XX)
•
10 Foot High-pressure Hose kit (P/N: 163-184104-XX)
•
15 Foot High-pressure Hose kit (P/N: 163-183103-XX)
•
30 Foot High-pressure Hose kit (P/N: 163-182102-XX)
Used components
The following is a list of parts used from the kits listed above.
Description
½" PT male-to- ½" NPT female adapter
½" NPT male-to-female 90° elbow—quantity 2
Male (plug) quick-disconnect
Female (socket) quick disconnect
Installing the SMC HRS-040 Chiller Instruction Sheet
020-103867-02 Rev. 1 (01-2024)
Copyright
©
2024 Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.
Kit part number
163-186106-XX
163-185105-XX
163-185105-XX
163-185105-XX
1
Advertisement
Related Manuals for Christie SMC HRS-040
Summary of Contents for Christie SMC HRS-040
- Page 1 Installing and setting up the SMC HRS-040 chiller This document provides information on how to install and set up the SMC HRS-040 chiller plumbing kit. Affected products The following products are affected: • CP4440-RGB • CP4445-RGB • CP4450-RGB • CP4455-RGB Required components and tools The following components and tools are required.
-
Page 2: Safety And Warning Guidelines
• Safety glasses Safety and warning guidelines Read all safety and warning guidelines before installing or operating the SMC HRS-040 chiller. Caution! If not avoided, the following could result in minor or moderate injury. • Use protective eye wear and gloves. Follow workplace guidelines for using personal protective equipment when installing, cleaning, and servicing the product. - Page 3 Installing and setting up the SMC HRS-040 chiller Alarm code labels can be found in the chiller accessories bag. Assembling the chiller connections Follow these steps to assemble the chiller connections. 1. To prevent rolling, lock the front wheels and place on a flat surface.
- Page 4 Installing and setting up the SMC HRS-040 chiller 5. Install the sub-assembly to the chiller outlet, making sure the assembly is facing down. 6. Remove the plastic cap from the chiller return port. 7. Apply three to four rounds of grey sealant tape to the following components: •...
- Page 5 Installing and setting up the SMC HRS-040 chiller Make sure to leave the first few threads at the end of the components free of tape. 8. Install the female (socket) quick-disconnect (A in the image in step 9) to the ½” NPT male-to- female elbow (B in the image in step 9).
- Page 6 Installing and setting up the SMC HRS-040 chiller Assembling the hose Follow these steps to assemble the hose. 1. Apply three or four rounds of sealant tape to the following items from the Chiller Connection kit (P/N: 163-187107-XX): • Two SAE 8 female x 1/2" NPT male straight adapters (A in image below) •...
-
Page 7: Starting The Chiller
Installing and setting up the SMC HRS-040 chiller 8. Use a pair of adjustable wrenches to tighten both ends. 9. Connect the hose kit to the outlet and return port of the chiller. Starting the chiller Follow these steps to start the chiller. - Page 8 Installing and setting up the SMC HRS-040 chiller Connecting the SMC serial cable The SMC chiller cable needs an adapter to plug into the back of the chiller. 1. Plug the adapter (P/N:001-115197-XX) into the back of the chiller. 2. Plug the chiller cable (P/N: 001-112405-XX) into the adapter on the back of the chiller.
- Page 9 Installing and setting up the SMC HRS-040 chiller Controlling the chiller You can control the chiller from either the projector or the control panel. You only need to control the chiller from the control panel if the remote LED indicator is on.
- Page 10 Installing and setting up the SMC HRS-040 chiller g) Select the SEL button to display the Communication menu 4. h) Use the Up/Down buttons to select on. Select the SEL button to display the Communication menu 5. Make sure the second line reads 1.
- Page 11 Installing and setting up the SMC HRS-040 chiller 6. Use the Up/Down buttons to select 37.0. This sets the maximum coolant temperature to 37°C (98.6°F). If the coolant temperature exceeds 37°C (98.6°F) in the chiller, the chiller still operates but an alarm is triggered.
-
Page 12: Technical Support
Installing and setting up the SMC HRS-040 chiller 12. To return to the main menu, select the Menu button. Technical support Technical support for Christie Cinema products is available at: • Support.cinema@christiedigital.com • +1-877-334-4267 • Christie Professional Services: +1-800-550-3061 or NOC@christiedigital.com Installing the SMC HRS-040 Chiller Instruction Sheet 020-103867-02 Rev.
