WARNING: Clear the area to be cut before each
use. Remove all objects, such as rocks, broken glass,
nails, wire, or string that can be thrown or become
entangled in the cutting attachment. Clear the area of
children, bystanders, and pets. At a minimum, keep
all children, bystanders and pets at least 15m away;
there still may be risk to bystanders from thrown
objects. Bystanders should be encouraged to wear eye
protection. If you are approached, stop the motor and
cutting attachment immediately.
For safe and better operation, put on the shoulder
strap across the shoulder. Adjust the shoulder strap
in a comfortable operating position. Hold the line
trimmer with your one hand on the rear handle and
your other hand on the front handle. Keep a firm grip
with both hands while in operation. The line trimmer
should be held at a comfortable position with the rear
handle about hip height. The trimmer head should
be parallel to the ground so that it easily contacts the
material to be cut without the operator having to bend
over (Fig. B).
WARNING: The shoulder strap is also a quick
release mechanism in hazardous situation. When
emergency occurs, take it off from your shoulder
immediately, no matter what way the strap is in.
After each use, clean the trimmer
See the MAINTENANCE section for cleaning instructions.
TO START/STOP THE TOOL
See "STARTING/STOPPING THE POWER HEAD" section
in the power head PH1420E operator's manual.
ADJUSTING CUTTING LINE LENGTH
The trimmer head allows the operator to release more
cutting line without stopping the motor. As line becomes
frayed or worn, additional line can be released by lightly
tapping the trimmer head on the ground while operating
the trimmer (Fig. E).
NOTICE:
Line release will become more difficult as the
cutting line becomes shorter.
WARNING:
Do not remove or alter the line-cutting
blade assembly. Excessive line length will cause the motor to
overheat and may result in serious personal injury.

LINE REPLACEMENT

NOTICE: Always use the recommended nylon cutting line
with diameter no more than 2.4mm. Using line other than
that specified may cause the line trimmer to overheat or
become damaged.
10
56 VOLT LITHIUM-ION LINE TRIMMER ATTACHMENT — STA1600
WARNING:
Never use metal-reinforced line, wire,
or rope, etc. These can break off and become dangerous
projectiles.
The line trimmer is equipped with an advanced
POWERLOAD system. The cutting line can be wound into
TM
the spool simply by pressing a single button. Loading a
full spool can usually be completed in 12 seconds. Avoid
repeated operation of the winding system in rapid
succession to reduce the possibility of motor damage.
NOTICE:
The POWERLOAD
the attachment is connected to Power Head PH1420E and
the battery pack is installed.
1. Remove the battery pack.
2. Cut 4m long cutting line. Insert the line into the eyelet
(Fig. F). Push and pull the line from the other side
until equal amounts of the line appear on both sides
of the trimmer head
NOTICE:
If the line cannot be inserted into the eyelet when
the lower cover is stuck, install the battery pack onto the
power head, then press the line-loading button briefly to
reset the lower cover.
3. Remove the battery pack if it has been installed
onto the power head in the NOTICE after step 2. And
follow the steps specified in step 2 to reinsert and
align the cutting line.
4. Install the battery pack onto the power head.
5. Press and hold the line-loading button to wind
the line into the trimmer head continuously until
approximately 15 cm of the line is showing on each
side. (Fig. G).
6. Push down on the trimmer head while pulling on the
lines to manually advance the line in order to check
for proper assembly of the cutting line.
NOTICE:
In case the line is pulled into the trimmer head
by accident, open the head and pull the cutting line out
from the spool. Follow the section "RELOADING THE
CUTTING LINE" in this manual to reload the line.
RELOADING THE CUTTING LINE
When the cutting line breaks from the eyelet or the
cutting line is not released when the trimmer head is
tapped, you will need to remove the remaining cutting
line from the trimmer head and follow the steps below
to reload the line.
1. Remove the battery pack.
2. Press the release tabs on the trimmer head and
remove the lower cover assembly of the trimmer
head by pulling it straight out (Fig. H).
TM system is only available when
