Yale Assure Lock 2 Touch Manual page 6

1/8 3/8 5/8 7/8 1/8 3/8
1/4 3/4 1/4
1/2
0 1
I
Door Checker Part 2
Measure Face Bore
Equals G or H
Less than G
(Adjust diameter to G or H)
Greater than H
(Your door is not a match)
G. 1-1/2" face bore diameter.
H. 2-1/8" face bore diameter.
5/8 7/8 1/8 3/8 5/8
3/4 1/4 3/4
1/2 1/2
2
G H
Measure Edge Bore and Strike Pocket
Equals I
Less than I
(Adjust diameter to I)
Greater than I
(Your door is not a match)
I. 1" edge bore diameter;
1" strike pocket diameter and depth.
7/8 1/8 3/8 5/8 7/8 1/8
1/4 3/4 1/4
1/2
3 4
Door (Edge Bore)
P/N YRD420-KD-F Rev A
3/8 5/8 7/8
3/4
1/2
5
If printed from electronic file, Measure
ruler to check scale. Set print scale to 1:1.
See Reverse for Part 1
Frame (Strike Pocket)
Diameter
Minimum strike pocket depth is 1".
6
Depth
