- Page 1 Instruction Sheet IS-44 Gecko-MT Hand Crimp Tools Z125-903 & Z125-904 Tool in nearly Safety Clips closed position Selector Knob Positioner Positioner Locator // HARWIN.COM...
- Page 2 IS-44 Instruction Sheet for Gecko-MT Hand Crimp Tool Z125-903/904 (MH820) CRIMP CONTACT INFORMATION This Hand Crimp Tool has been designed for use with the following Gecko-MT Power Crimp Contacts: G125-0500005 ............Female crimp contact for 18 AWG wire G125-1500005 ............Male crimp contact for 18 AWG wire ...
- Page 3 IS-44 Instruction Sheet for Gecko-MT Hand Crimp Tool Z125-903/904 (MH820) Cut the end of the cable to be terminated so that there is a clean cut end (Figure A). Strip the cable to the correct length (Figure B). We recommend that when the wire is stripped, it is clamped or supported close to the stripping area - this will prevent insulation slippage.
- Page 4 IS-44 Instruction Sheet for Gecko-MT Hand Crimp Tool Z125-903/904 (MH820) CARE OF TOOL There is virtually no maintenance required for the Z125-903 tool. However, it is good practice to keep the indenter tips free of debris. A small wire brush may be used for this purpose. We strongly recommend that you: ...
