HAND CRIMP TOOLS Z80-292 & Z80-293
Positioner
Guide
Selector
Index
Positioner Z80-291
Z80-292 (open position)
These Hand Crimp Tools have been designed for use with the following Datamate Mix-Tek Coax contacts
(Z80-292 must be used with positioner Z80-291):
M80-305 & 307 ........................................... Straight female coax crimp contact
M80-308 & 309 (Z80-293 only) ................. 90° female coax solder/crimp contact
M80-315 & 317 ............................................ Straight male coax crimp contact
M80-318 & 319 (Z80-293 only) .................. 90° male coax solder/crimp contact
Contents ................................................................................................................................................... 1
General information ................................................................................................................................ 2
Tool preparation ...................................................................................................................................... 2
Wire stripping details .............................................................................................................................. 3
Crimping procedure Z80-292 .................................................................................................................. 3
Crimping procedure Z80-293................................................................................................................... 4
Care of tool .............................................................................................................................................. 4
Harwin North America
T: +1 603 893 5376
E: mis@harwin.com W: www.harwin.com
IS-34
Issue: 6
Date: 26.04.2022
Safety Clip
(Used in Mix-Tek female crimp connectors)
(Used in Mix-Tek female crimp connectors)
(Used in Mix-Tek male crimp connectors)
(Used in Mix-Tek male crimp connectors)
CONTENTS
Harwin Europe
T: +44 (0) 23 9231 4545
E: mis@harwin.co.uk W: www.harwin.com
C/Order: 31490
Die Set
Z80-293 (closed position)
Harwin Asia
T: +65 6 779 4909
E: mis@harwinasia.com W: www.harwin.com
Page 1 of 4
