Power Wizard PW-250 Operating
Instructions
Important Note:
Power Wizard
They are not intended for use in validating critical process parameters and should not be used in such
applications.
Note: Read these instructions thoroughly before using the PW-250. Certain steps in the measurement process must be
made in a timely manner to prevent erroneous power readings.
Setup
1
Position a beam block in a manner that prevents the laser beam from traveling beyond the work area during power
measurements.
2
Ensure that all personnel in the area are wearing the appropriate protective eyewear.
Apply power to the laser. Enable lasing just as you are ready to begin power measurements.
3
Danger
serious
personal
injury
®
power meters are designed as diagnostic and service tools for verifying laser power.
Direct or diffuse laser radiation can inflict severe bodily damage, including, but not
limited to, permanent eye damage or blindness, and severe burns to human or animal
tissue. Always wear the appropriate eye protection when in the same area as an operat-
ing laser. Do not allow a direct or reflected beam to contact a person.
Always be aware of the laser's beam path when using a laser power meter and always
use a beam block to prevent the beam from traveling beyond the intended work area.
Rev 3 / 18 Apr 2014
P/N 900-00005-02

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Power Wizard PW-250 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Synrad Power Wizard PW-250

Summary of Contents for Synrad Power Wizard PW-250

  • Page 1 4600 Campus Place Mukilteo, WA 98275 1.425.349.3500 1.425.349.3667 e-mail synrad@synrad.com www.synrad.com Power Wizard PW-250 Operating Instructions ® Important Note: Power Wizard power meters are designed as diagnostic and service tools for verifying laser power. They are not intended for use in validating critical process parameters and should not be used in such applications.

  • Page 2: Power Measurements

    Power Wizard PW-250 Operating Instructions (cont.) Power measurements Hold the PW-250 so that the LCD display is in your hand with the black anodized target facing away from you. Press and hold the RESET/POWER button for at least two seconds. This activates the PW-250 and initializes the measurement computer.

  • Page 3: Maintenance

    SYNRAD, Inc. will repair or replace at no charge any PW-250 that fails due to manufacturing or design defect. Defective unit must be returned to SYNRAD, Inc. freight prepaid. Prior to returning the unit, you must first obtain a Return Authorization (RA) number by calling SYNRAD Customer Service at 1.800.796.7231, outside the U.S.

  • Page 4: Specifications

    Power Wizard PW-250 Operating Instructions (cont.) The useful temperature range of the target is 0–150 °C (32–302 °F). Accurate measurements can be performed at any tem- perature in between. Damage to the target and sensor can occur if the temperature of the target exceeds 180 °C (356 °F).

  • Page 5: Declaration Of Conformity

    IEC 1000-4-2:1995 Electrostatic Discharge Immunity IEC 1000-4-3:1995 RF Electromagnetic Fields Immunity IEC 1000-4-4:1995 Electrical Fast Transient/Burst Immunity Corporate Officer: European Contact: Excel Technology Europe GmbH Münchner Str. 2a D-82152 Planegg Germany Dave Clarke, President of SYNRAD, Inc. Dated 01 September 2009...
