Connection of Talkback Speakers
(V-2003AHF Only)
Using twisted pair telephone wire, connect:
Zone 1 Speaker Tip, Ring
Zone 2 Speakers Tip, Ring
Zone 3 Speakers Tip, Ring
No more than two (2) 45-Ohm speakers
should be connected to any talkback zone.
Do not use 8-Ohm speakers.
Wiring Instructions for Page Port Access
A connection block with a 50 pin female
amphenol connector must be used to
crossconnect speakers and options. See Figure
2 for 66 block pinouts.
When used with page port access, the
V-2003A/V-2003AHF may only be used with a
600 Ohm page port that will pass DTMF tones
for zone selection and that is equipped with a
contact closure. Additionally, the page port must
be capable of passing bi-directional audio for
talkback operation.
___1. Make certain Battery Feed Switch
(SW2) is OFF (In the UP position, See
Figure 3).
___2. Plug 50-pin female Amphenol connector
into J2 of the V-2003A/V-2003AHF.
___3. Connect Tip and Ring Audio of Page
Port to Tip (W/BL) and Ring (BL/W) of
the connection block.
___4. Connect wiring from telephone system
Page Port Dry Contact Closure to the
W/O, O/W pair of the
V-2003A/V-2003AHF connection block.

Power Connections

NOTE: This equipment must be installed
near an AC power outlet due to the power
cord being used as a disconnect device.
The V-2003A/V-2003AHF is provided with one a
NEMA 5-15 cord set for North American use.
Refer to Figure 4 for the voltage selector
switch and fuse location. Make certain the
voltage selector switch is placed at the
appropriate rating and that the proper rated
fuse is installed.
-BK/G, G/BK
-BK/BR, BR/BK
-BK/S, S/BK
5
•
Connect cord set to unit via IEC 320 female
connector located on one end of cord set to
IEC 320 male appliance couple located on
the V-2003A/V-2003AHF.
•
For 115VAC use, verify fuse rating of 1 Amp
and voltage selector switch displays 115V.
•
For 230VAC use, verify fuse rating of 0.5
Amp and voltage selector switch displays
230V.
•
After all required connections have been
made, plug the cord set into appropriate AC
wall outlet.
V-2003A Volume Adjustments
There are two volume controls on the unit for
individual adjustment of:
•
Background Music
•
Tones (Warble/single tone)
Clockwise adjustment increases volume,
counter clockwise decrease volume. During
initial set up, adjust individual speaker volume
controls to the desired page level first, then
adjust volume on page unit to the desired level
for music and tones.
V-2003AHF Volume Adjustments
There are five additional volume controls on the
V-2003AHF to control the volume of the
handsfree talkback outputs. They are:
•
Page (Adjusts volume of page during all call
on handsfree outputs)
•
Speaker to Phone (Adjusts response
volume from the speaker; should be turned
as low as possible)
•
Phone to Speaker (Adjusts volume of a
page from phone)
•
Background Music (Adjusts background
music on handsfree outputs)
•
Tones (Adjusts the volume of single and
warble tones on handsfree outputs)
Refer to Figure 4 for locations of the volume
controls.
One-way Speakers may be connected to low
level outputs on the V-2003AHF for zones
programmed for one-way paging.

Connections for the V-2003AHF

The V-2003AHF is programmable on a per zone
basis for one-way or talkback communication. A
single talkback zone may have both one-way
and talkback speakers. One-way amplified
speakers may be connected to the handsfree
