Valcom V-1030M Manual page 2

Applications of the V-1030M and
V-1036M
Use with Valcom page control
Expanding the capability of telephone systems
which contain limited paging capabilities
Loud ringer application in systems where
loud-speaker tone signaling is employed.
V-1030M - Nominal Specifications
Input Impedance:
Input level:
Current at -24VDC:
V-1036M - Nominal Specifications
Input Impedance:
Input level:
Current at -24VDC:
Horn Spacing for the
V-1030M/V-1036M
(coverage shown in parenthesis)
V-1030M
Location 5 Watt
Quiet 110'
(12,000 sq. ft.)
Moderate
(6,400 sq. ft.)
Noisy
(2,500 sq. ft.)
Very Noisy
(900 sq. ft.)
Example: In a quiet environment, V-1030M 5 Watt
horns would be spaced 110 feet apart side to side and
would provide good quality sound 110 feet in front of
each horn approximately 12,000 sq. ft. of coverage.
Definitions:
Quiet: 50-65dB. This would include stock areas, etc.
Moderate: 65-80dB. This includes areas such as
warehouses, shipping areas or light manufacturing.
Noisy: 80-90dB. This includes machine shops or
heavy manufacturing.
Very Noisy: Greater than 90dB. This would include
any areas where talking to another person is very
difficult. Workers may be required to wear earplugs.
600 Ohm nominal
-15dBm to +10dBm
300mA
600 Ohm nominal
-15dBm to +10dBm
900mA
V-1036M
15 Watt
N/A
80' N/A
50' 75'
(5,600 sq. ft.)
30' 45'
(2,000 sq. ft.)
Audio Wire Runs (V-1030M/V-1036M)
When a remote power unit is used, the audio pair run
should be limited to 5000 feet and a maximum of 4
horns when using 24AWG wire. A V-1094A may be
added to increase the number of horns and/or distance.
Twisted pair wire (standard telephone wire) should be
used for connections.
Power Wire Run (V-1030M/V-1036M)
For good quality sound, the distance recommended
between the power supply and horns should be adhered
to.
Number of Horns
per Power Run
15 Watt
V-1036M V-1030M
1
0
0
See the Valcom power run gauge guide for additional
wire gauges and distances.
Wiring Connections
(V-1030M/V-1036M)
Twisted pair wire (standard telephone wire) should be
used for connections.
Audio In
Green
Red
Power In
Black
White
Brown
SPECIFICATIONS/
CONNECTIONS FOR THE
V-1048M
Application
The V-1048M talkback horn is designed to be used
with "handsfree" talkback control units. In combination
with these units, the speaker provides both loudspeaker
and talkback functions.
A standard talkback paging system is comprised of
three basic components:
1. Talkback page control unit
2. Speakers
3. Power Supply
2
Wire Run Length
(feet)
5 Watt
24AWG
4 125
2 250
1 500
- Tip
- Ring
- Ground
- (-24VDC)
- Not Used
22AWG
200
400
800
