- Page 1 Delta 48V 3U Lithium-ion Battery Module SEG-48100-02I Operation Manual www.deltaelectronicsindia.com...
-
Page 2: Table Of Contents
Application : 3U 100 Ah Telecom LIB Guide 1.1 Scope 1.2 Package Content 1.3 Safety Notice 1.3.1 Legal and Safety Information 1.3.2 Limitation 1.3.3 Third Party Devices 1.4 Special Instruction 1.4.1 Operation Notice 1.4.2 Safety Notice 1.4.3 General Notice Product Specification 2.1 Overview 2.2 Specification 2.3 Appearance... -
Page 3: Guide
Package Content During the transportation process, some unpredictable circumstances may cause product damage. It is recommended that to check the basic product appearance and checklist. If found any missing parts or damage, please contact Delta Electronics India. Item Description Quantity... -
Page 4: Limitation
Third-party components and/or services, such as distribution boxes or GPS repair or maintenance or use or improper use of the equipment, Delta is not responsible. In addition, Delta shall not be liable for any malfunction, danger, or damage to the equipment of any third party component or service. -
Page 5: Operation Notice
7. Do not pierce the battery with nails or other sharp objects. Do not throw, step on, strike, or hit the battery. 8. It is forbidden to disassemble batteries and components. Delta will not be responsible for any damage caused by unauthorized disassembly or maintenance... -
Page 6: General Notice
Product Specification Overview The SEG-48100-02I lithium-ion battery is an external battery system that provides backup power for 48V devices. When the Input AC power supply is normal, the rectifier power module supplies power to the device and charges the battery pack. When the mains power is off, the rectifier power module stops supplying power. -
Page 7: Appearance
Specification Details Rated discharging current (A) 100 A (Max) 50 A (Rated) Operating temperature 0℃〜55℃ (Charging) -20℃〜60℃ (Discharging) Nominal Storage temperature 0℃〜+30℃ Relative humidity 5%〜95%RH (Non-Condensing) Operating Altitude ≤2000m (Max) Note! It is recommended to store the Battery in the ventilated, damp-proof, anti-corrosion and dustproof environment with relative humidity not over 50% and room temperature of 25℃... -
Page 8: Dimention
Dimention Installation Preparation Installation, operation, and maintenance of the SEG-48100-02I lithium-ion battery system can only be performed by trained and qualified personnel. Before installation and use, please read carefully the safety precautions and related operating procedures of this product. The installation process should strictly abide by the following safety regulations and local safety regulations, otherwise it may result in personal injury or product damage. -
Page 9: Environment Requirement
1. Make sure that the power system connected to the battery is a qualified communication power system. 2. When installing the battery, please make sure that the power supply system is in the off state without current, and that the battery module is turned off. 3. -
Page 10: Power Source Confirmation
Power Source Confirmation – Check that the device properties directly connected to the battery are user equipment, switching power supplies, or other power devices. – Check the position of the DC interface in the device and the output voltage to see if it meets the voltage requirements. -
Page 11: Unpacking The Battery Module
Unpacking the battery Module Unpacked the battery module from the box and inspect the battery case for deformation, breakage, and loosening, if found please contact with Delta. 3.6.2 Placement of Battery Insert the battery module one by one in cabinet & Screw the battery with rack. -
Page 12: Interconnection Of Battery With Power Plant
Positive point, make sure SMPS based power plant should capable to handle LIB Battery. Connect Main power wire with power plant Warning! If there are any problems during installation, please contact Delta service personnel immediately to avoid equipment damage or safety accidents. 3.6.5 Communication Cable Installation:... -
Page 13: Pin Configuration
Set the address of each battery bank as below 3.6.6 Pin configuration Battery Pin P1 or P3 or P6 D- / Low Line Data P2 or P7 D+ / High Line Data... -
Page 14: Start The Battery Module
If the battery does not start up normally or the ALM light on the display is on, disconnect the power cord and reinstall it. Press reset button if required, if this does not solve the problem, contact Delta's service personnel in a timely manner to avoid damaging the device or causing a safety accident. -
Page 15: Capacity Indication
Capacity Indication Status Charging Discharging “CHARGE” LED Indication L1 0% ~ 25% Blinking OFF 25% ~ 50% Blinking OFF 50% ~ 75% Blinking OFF 75% ~ 100% Blinking ON Shipping, Storage, and Maintenance Shipping Packaged products can be transported using general purpose transport but should avoid throwing, rain, strong radiation and Erosion of corrosives;... -
Page 16: Periodic Maintenance
– Cleaning method To perform a standard cleaning of the battery, follow the procedure below: Disconnect the battery. Wipe off any accumulation of dust on the battery covers with a cloth Periodic Maintenance When the battery module is shipped from the factory, the SOC is 60%-65%. If it is left unused for a long time, it must be charged within 3 months to avoid over-discharge of the battery. - Page 17 Our mission is to provide innovative, clean and energy-efficient solutions for a better tomorrow End of Product Manual www.deltaelectronicsindia.com...
