MSI PRO AP162T ADL User Manual page 6

Side View
Power Button
1
Press the power button to turn the system on and off.
Power LED
2
The power LED glows when the system is turned on and goes off when
the system is shut down. In terms of power saving, the LED blinks in S3
(Suspend to RAM) mode and goes off in S4 (Suspend to Disk) mode.
Hard Disk Drive LED
3
This indicator shows the activity status of the HDD. It flashes when the
system is accessing data on the HDD and remains off when no disk activity
is detected.
Brightness Button
4
These buttons adjust the brightness level.
Card Reader
5
The built-in card reader supports various types of memory cards.
USB 3.2 Gen 2 Port
6
This connector is provided for USB peripheral devices. (Speed up to 10
Gbps)
1
2
3
4
5
6
7
8
6
