PRO Series
LCD Monitor
PRO MP2412C (3PA9)
User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PRO MP2412C and is the answer not in the manual?

Questions and answers

Summary of Contents for MSI PRO MP2412C

  • Page 1 PRO Series LCD Monitor PRO MP2412C (3PA9) User Guide...
  • Page 2: Table Of Contents

    Contents Getting Started ......................3 Package Contents ....................3 Installing the Monitor Stand ................... 4 Adjusting the Monitor ..................... 5 Monitor Overview ....................6 Connecting the Monitor to PC ................7 OSD Setup ........................8 OSD Keys ........................ 8 OSD Menus........................10 Luminance ......................
  • Page 3: Getting Started

    This chapter provides you with the information on hardware setup procedures. While connecting devices, be careful in holding the devices and use a grounded wrist strap to avoid static electricity. Package Contents Monitor PRO MP2412C Documentation Quick Start Guide Accessories Stand...
  • Page 4: Installing The Monitor Stand

    Installing the Monitor Stand 1. Leave the monitor in its protective foam packaging. Align, insert and push the stand bracket towards the monitor groove until it locks in place. 2. In case of improper installation, push the release tab to release and reinstall the stand.
  • Page 5: Adjusting The Monitor

    Adjusting the Monitor This monitor is designed to maximize your viewing comfort with its adjustment capabilities. ⚠ Important Avoid touching the display panel when adjusting the monitor.
  • Page 6: Monitor Overview

    Monitor Overview OSD Keys Power Button Kensington Lock Power Jack DisplayPort Supports 1920x1080@100Hz as specified in DisplayPort 1.2a. HDMI™ Connector Supports 1920x1080@100Hz as specified in HDMI™ 1.4b. Headphone Jack...
  • Page 7: Connecting The Monitor To Pc

    Connecting the Monitor to PC 1. Turn off your computer. 2. Connect the video cable from the monitor to your computer. 3. Connect the power cord to the monitor power jack. (Figure A) 4. Plug the power cord into the electrical outlet. (Figure B) 5.
  • Page 8: Osd Setup

    OSD Setup ⚠ This chapter provides you with essential information on OSD Setup. Important All information is subject to change without prior notice. OSD Keys The monitor comes with a set of OSD Keys that help to control the On-Screen Display (OSD) menu.
  • Page 9 OSD Keys Hot Key (When OSD is OFF) OSD Setup (When OSD is ON) AUTO / ∙ Selecting the video input ∙ Returning to the previous SOURCE / from external sources menu EXIT ∙ Activating the Auto ∙ Exiting from the OSD Main Adjustment function to Menu optimize the horizontal...
  • Page 10: Osd Menus

    OSD Menus Luminance 1st Level Menu 2nd Level Menu Description Contrast 0-100 ∙ This function is available in Standard mode. Brightness 0-100 ∙ This function is available in Standard mode. Eco Mode Standard ∙ Activating Eco Mode will affect: Text Affected Function Function Status »...
  • Page 11: Image Setup

    Image Setup 1st Level Menu 2nd Level Menu Description Image Ratio Wide ∙ Selecting the Image Aspect Ratio Overdrive Normal ∙ Overshooting may occur when Overdrive is set to Fastest. Fast Fastest Adaptive-Sync ∙ Adaptive-Sync prevents screen tearing. ∙ Activating Adaptive-Sync will affect: Affected Function Function Status »...
  • Page 12: Osd Setup

    OSD Setup 1st Level Menu 2nd Level Menu Description H. Position 0-100 ∙ Adjusting the horizontal position of OSD V. Position 0-100 ∙ Adjusting the vertical position of OSD Timeout 5-100 ∙ Adjusting the OSD timeout Language English ∙ Selecting the OSD language Español Français Português...
  • Page 13: Specifications

    Specifications Monitor PRO MP2412C Size 23.6 inch Curvature 1500R Panel Type 1920 x 1080 Resolution Aspect Ratio 16:9 Brightness (nits) Contrast Ratio 3000 : 1 Refresh Rate 100Hz Response Time ∙ 4ms (GTG) ∙ 1ms (MPRT) ∙ HDMI™ Connector x1 ∙...
  • Page 14 Monitor PRO MP2412C Dimension (W x H x D) 537 x 407 x 237 mm Weight 4.0 Kg Gross 5.5 Kg Environment Operating ∙ Temperature: 0℃ ~ 40℃ ∙ Humidity: 20% ~ 90%, non-condensing ∙ Altitude: 0 ~ 5000m Storage ∙...
  • Page 15: Preset Display Modes

    Preset Display Modes ⚠ Important All information is subject to change without prior notice. Standard Resolution HDMI™ 640x480 @60Hz @67Hz @72Hz @75Hz SVGA 800x600 @56Hz @60Hz @72Hz @75Hz 832×624 @75Hz 1024x768 @60Hz @70Hz @75Hz 1280×720 @60Hz SXGA 1280×960 @60Hz WXGA 1280x1024 @60Hz @75Hz...
  • Page 16: Troubleshooting

    Troubleshooting The power LED is off. • Press the monitor power button again. • Check if the monitor power cable is properly connected. No image. • Check if the computer graphics card is properly installed. • Check if the computer and monitor are connected to electrical outlets and are turned on.
  • Page 17: Safety Instructions

    ∙ Place the power cord in a way that people are unlikely to step on it. Do not place anything on the power cord. ∙ If this device comes with an adapter, use only the MSI provided AC adapter approved for use with this device.
  • Page 18 ∙ If any of the following situations arises, get the device checked by service personnel: • The power cord or plug is damaged. • Liquid has penetrated into the device. • The device has been exposed to moisture. • The device does not work well or you can not get it working according to the User Guide.
  • Page 19: Tüv Rheinland Certification

    TÜV Rheinland Certification TÜV Rheinland Low Blue Light Certification Blue light has been shown to cause eye fatigue and discomfort. MSI now offers monitors with TÜV Rheinland Low Blue Light certification to ensure users’ eye comfort and well-being. Please follow the instructions below to reduce the symptoms from extended exposure to the screen and blue light.
  • Page 20: Regulatory Notices

    1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. MSI Computer Corp. 901 Canada Court, City of Industry, CA 91748, USA (626) 913-0828 www.msi.com...
  • Page 21 Vietnam RoHS As from December 1, 2012, all products manufactured by MSI comply with Circular 30/2011/TT-BCT temporarily regulating the permitted limits for a number of hazardous substances in electronic and electric products.
  • Page 22 Copyright and Trademarks Notice Copyright © Micro-Star Int’l Co., Ltd. All rights reserved. The MSI logo used is a registered trademark of Micro-Star Int’l Co., Ltd. All other marks and names mentioned may be trademarks of their respective owners.
