  • Page 1 PRO Series LCD Monitor PRO MP221 (3BA2)
  • Page 2: Table Of Contents

    Contents Copyright and Trademarks Notice ��������������������������������������������������������������������������iii Revision ������������������������������������������������������������������������������������������������������������������iii Technical Support ���������������������������������������������������������������������������������������������������iii Safety Instructions ���������������������������������������������������������������������������������������������������iv CE Conformity ���������������������������������������������������������������������������������������������������������vi FCC-B Radio Frequency Interference Statement ���������������������������������������������������vi WEEE Statement ���������������������������������������������������������������������������������������������������vii Chemical Substances Information �������������������������������������������������������������������������vii RoHS Statement ����������������������������������������������������������������������������������������������������vii Getting Started �������������������������������������������������������������������������������1-1 Package Contents ������������������������������������������������������������������������������������������������ 1-2 Installing the Monitor Stand ����������������������������������������������������������������������������������...
  • Page 3: Copyright And Trademarks Notice

    Preface Copyright and Trademarks Notice Copyright © Micro-Star Int’l Co�, Ltd� All rights reserved� The MSI logo used is a registered trademark of Micro-Star Int’l Co�, Ltd� All other marks and names mentioned may be trademarks of their respective owners� No warranty as to accuracy or completeness is expressed or implied�...
  • Page 4: Safety Instructions

    Safety Instructions ◙ Read the safety instructions carefully and thoroughly� ◙ All cautions and warnings on the device or user’s manual should be noted� ◙ Refer servicing to qualified personnel only. Keep the User’s Guide that comes with the package for future reference� To prevent fire or shock hazard, keep this device away from humidity and high temperature�...
  • Page 5 Users should contact the local authorized point of collection for recycling and disposing of their end-of-life products� ◙ Visit the MSI website and locate a nearby distributor for further recycling information� ◙ Users may also reach us at gpcontdev@msi�com for information regarding proper disposal, take-back, recycling, and disassembly of MSI products�...
  • Page 6: Ce Conformity

    1� this device may not cause harmful interference, and 2� this device must accept any interference received, including interference that may cause undesired operation� MSI Computer Corp� 901 Canada Court, City of Industry, CA 91748, USA (626)913-0828 www�msi�com...
  • Page 7: Weee Statement

    Vietnam RoHS As from December 1, 2012, all products manufactured by MSI comply with Circular 30/2011/TT-BCT temporarily regulating the permitted limits for a number of hazardous substances in electronic and electric products�...
  • Page 9: Getting Started

    Getting Started This chapter provides you with the information on hardware setup procedures� While connecting devices, be careful in holding the devices and use a grounded wrist strap to avoid static electricity� IMPORTANT The illustrations are for reference only� Your monitor may vary in appearance�...
  • Page 10: Package Contents

    Package Contents 1� Monitor 2� Stand with Base 3� Power Cord 4� HDMI Cable 5� D-Sub Cable 6� Quick Start Guide 7� Warranty Card * Contact your place of purchase or local distributor if any of the items is damaged or missing�...
  • Page 11: Installing The Monitor Stand

    Getting Started Installing the Monitor Stand IMPORTANT Place the monitor on a soft, protected surface to avoid scratching the display panel� 1� Align the latch of the stand with base to the monitor and push it� 2� When the stand with base is secured to the monitor, a click sound will be heard� 3�...
  • Page 12: Adjusting The Monitor

    Adjusting the Monitor This monitor is designed to maximize your viewing comfort with its adjustment capabilities� IMPORTANT Avoid touching the display panel when adjusting the monitor�...
  • Page 13: Monitor Overview

    Getting Started Monitor Overview D-SUB Power Jack HDMI Port D-Sub Port OSD Keys Power LED Kensington Lock...
  • Page 14: Connecting The Monitor To Pc

    Connecting the Monitor to PC 1� Turn off your computer. 2� Connect the HDMI/DisplayPort cable from the monitor to your computer� 3� Connect the power cord to the monitor power jack� (Figure A) 4� Plug the power cord into the electrical outlet� (Figure B) 5�...
  • Page 15: Osd Setup

    OSD Setup This chapter provides you with essential information on OSD Setup� IMPORTANT All information is subject to change without prior notice�...
  • Page 16: Osd Key

    OSD Key The monitor comes with a set of OSD Key that helps to control the On-Screen Display (OSD) menu� Without entering OSD menu, you can use these OSD keys as hot keys for quick settings� OSD Key Function Basic Operations Input selection ■...
  • Page 17: Osd Setup Menu

    OSD Setup OSD Setup Menu Press button to launch the On-Screen Display (OSD) main menu� In OSD screen, use buttons to tune the desired function to suit your personal preferences� These OSD keys operations are as follows� OSD Key Basic Operations ■...
  • Page 18 h Luminance 1st Level Menu 2nd/3rd Level Menu Description Contrast 0-100 Adjust contrast� This function is available in Standard modes� Brightness 0-100 Adjust brightness� This function is available in Standard modes� Eco Mode Standard Text Internet Game Movie Sports DCR enhances image quality by increasing the contrast of images�...
  • Page 19 OSD Setup h OSD Setup 1st Level Menu 2nd/3rd Level Menu Description H� Position 0-100 Adjust the horizontal position of the OSD. V� Position 0-100 Adjust the vertical position of the OSD� Timeout 5-100 Adjust the OSD timeout� Language English Language is an independent setting�...
  • Page 21: Appendix

    Appendix IMPORTANT All information is subject to change without prior notice�...
  • Page 22: Specifications

    Specifications Model PRO MP221(3BA2) Size 21�5 inch Panel Type Resolution 1920 x 1080 @60Hz Aspect Ratio 16:9 Brightness (nits) 250 cd/m2 (TYP) Contrast Ratio 1000:1 Refresh Rate 60Hz Response Time Input Interface ■ HDMI Port x1 ■ D-Sub Port x1 View Angles 170°(H) , 160°(V)
  • Page 23: Preset Display Modes

    Appendix Preset Display Modes PRO MP221(3BA2) Standard Resolution HDMI D-Sub 640x480 @60Hz 640x480 @67Hz 640x480 @72Hz 640x480 @75Hz Dos-Mode 720x400@70Hz SVGA 800x600 @56Hz 800x600 @60Hz 800x600 @72Hz 800x600 @75Hz 1024x768 @60Hz 1024x768 @70Hz 1024x768 @75Hz 1152x864 @75Hz SXGA 1280x1024 @60Hz...
  • Page 24: Troubleshooting

    Troubleshooting The power LED is off. ■ Press the monitor power button again� ■ Check if the monitor power cable is properly connected� No image� ■ Check if the computer graphics card is properly installed� ■ Check if the computer and monitor are connected to electrical outlets and are turned on�...
