- Page 1 Pro Series Portable Monitor PRO MP161(3PB7)
-
Page 2: Table Of Contents
Table of Contents Preparation for use ..........3 Packing contents ..........3 Installation of Monitor Stand ......3 Overview of Monitor ........5 Connecting to be the monitor of various devices ......6 OSD setting ...................7 OSD keys ..................7 OSD menu ..................8 Professional ..................8 Image ....................9 Input source..................10 Navi key..................11 Setting ...................12... -
Page 3: Preparation For Use
Preparation for use The information for hardware installation programs is provided in this chapter. Before connecting to devices, be careful to fix the devices and use grounding wrist strap to avoid static electricity. Packaging contents Monitor PRO MP161(3PB7) Document Quick Start Guide Signal cable Mini HDMI TM transmission cable Power cable/signal cable... - Page 4 Adjusting monitor stand Caution Place the monitor on a soft, protected surface to avoid scratching the display panel. Do not use any sharp objects on the panel. This product has no protective film, so the user does not need to remove it! Any mechanical damage to the product, including removal of the polarizing film, may affect the warranty repair! PRO MP161(3PB7)
-
Page 5: Overview Of Monitor
Overview of the monitor PRO MP161(3PB7) ① Power button ② Up/down key ③ Type-C interface ④ Type-C interface ⑤ Mini HDMI interface... -
Page 6: Connecting To Be The Monitor Of Various Devices
Connecting to be the monitor of various devices PC’s HDMI as the signal source Signal transmission Supply power Note: Supplied power shall be larger than 15W Laptop’s Type-C as the signal source Signal transmission Supply power Note: Supplied power shall be larger than 15W Mobile phone’s Type-C as the signal source Signal transmission Supply power... -
Page 7: Osd Setting
OSD setting The basic information for OSD setting is provided in this chapter. Caution Any change of the information is not subject to prior notice. OSD key A group of OSD keys are provided for this monitor, which help to control on screen display (OSD) menu. -
Page 8: Osd Menu
OSD menu Professional Level-1 menu Level 2/3 menu Description Mode Use [Up] or [Down] key to select and USER preview mode and effect. Press OK key to apply your type of Anti-Blue light mode. Movie Office Black-white Response time Normal Adjust [Response time]. -
Page 9: Image
Level-1 menu Level 2/3 menu Description Alarm Clock Location Left Top After setting time, press OK key to activate the timer. Right Top The default location of [Alarm Clock] Left Bottom is [Left Top]. The user can select the Right Bottom [Location] by himself. -
Page 10: Input Source
Level-1 menu Level 2/3 menu Description Image enhancement [Image enhancement] can improve the sharpness on the edge of the image. Weak Medium Strong Strongest Low Blue light [Low Blue Light] can protect your eyes against blue light. After it is enabled, [Low Blue Light] can adjust color temperature of the screen to a more yellowish tint. -
Page 11: Navi Key
Level-1 menu Level 2/3 menu Description Auto Scan The user can use Navi key to select the input source from the following states: When the monitor is in the power saving mode, [Auto Scan] is set as [Off]; “No signal” message box is displayed on the monitor. -
Page 12: Setting
Setting Level-1 menu Level 2/3 menu Description Language Traditional Chinese The default setting of [Language] is [English]. The user shall press OK key to confirm and apply English [Language] setting. French [Language] is an independent setting. The user’s German own language setting will replace the default Italian setting. -
Page 13: Specification
Specifications Model PRO MP161 (3PB7) Size 15.6 inch Type of panel Resolution 1920*1080@60Hz Aspect ratio 16:9 Brightness (nits) 250 nits (Typ.) Contrast 600:1 Refresh rate 60Hz Response time 4ms (Min.) Interface of input source Mini HDMI interface*1 Type-C interface*2 Mini HDMI interface*1 Type-C interface*2 Viewing angle 170°(H), 170°... -
Page 14: Preset Display Mode
Preset Display Mode Caution Any change of the information is not subject to prior notice. Standard Resolution PRO MP161(3PB7) HDMI TYPE-C1 TYPE-C2 640*480 @60Hz @67Hz Dos-Mode 720*480 @60Hz 720*576 @50Hz SVGA 800*600 @56Hz @60Hz XVGA 1024*768 @60Hz SXVGA 1280*1024 @60Hz WXGA+ 1440*900 @60Hz... -
Page 15: Troubleshooting
Troubleshooting The power LED indicator is not on. Press the power button on the monitor again. Check if the power cable of the monitor is properly connected. There’s no image. Check if the computer and graphics card are installed correctly. ... -
Page 16: Safety Precautions
Do not step on the power cable when placing it. Do not place anything on the power cable. If this device is equipped with an adapter, use only the AC adapter provided by MSI, which can be used for this device. - Page 17 Environment To reduce the injury caused by heat or overheating possibility of the device, do not place the device on a soft and unstable surface or block the ventilation holes of the device. Use this device only on a hard, flat and stable surface. ...
-
Page 18: German Rheinland Tuv Certifications
German Rheinland TUV Low Blue Light certification Blue light has been proven to cause eye fatigue and discomfort. MSI Microstar Technology now provides the screen that has been awarded the German Rheinland TUV low blue light certification to ensure the comfort and health of user’s eyes. -
Page 19: Regulatory Information
Chemical information Follow relevant chemical substance regulations, such as REACH Regulation (EC1907/2006 rules) of the European Union, and MSI provides chemical substance information of products on the following website, please visit: https://csr.msi.com/global/index... - Page 20 Name and content of harmful substances in the product Name of component Harmful substance Cr(VI) PBDE PCB component LCD display screen Cable/connector I/O device Speaker Metal mechanism Plastic mechanism/others Accessories (e.g.: power cable, etc) This table is made in accordance with SJ/T11364. O: indicates that the content of harmful substances in such component in all the homogeneous materials is below the limit specified in GB/T26572.
- Page 21 For more recycling information, please visit the MSI website and find the nearest dealer. The user can also send an email to gpcontdev@msi.com and contact us to learn about the information on disposal, recovery, recycling and disassembly of MSI products. Warning! Excessive use of the screen may damage your vision.
