Installation Instructions
Verification plug
KERN KIB-A12
Version 1.0
2019-02
GB
KERN & Sohn GmbH
Ziegelei 1
D-72336 Balingen
E-Mail: info@kern-sohn.com
Phone: +49-[0]7433- 9933-0
Fax: +49-[0]7433-9933-149
Internet: www.kern-sohn.com
KIB-A12-IA-e-1910

Advertisement

loading
Need help?

Need help?

Do you have a question about the KIB-A12 and is the answer not in the manual?

Questions and answers

Summary of Contents for KERN KIB-A12

  • Page 1 KERN & Sohn GmbH Ziegelei 1 Phone: +49-[0]7433- 9933-0 D-72336 Balingen Fax: +49-[0]7433-9933-149 E-Mail: info@kern-sohn.com Internet: www.kern-sohn.com Installation Instructions Verification plug KERN KIB-A12 Version 1.0 2019-02 KIB-A12-IA-e-1910...
  • Page 2: Table Of Contents

    KERN KIB-A12 Version 1.0 2019-02 Installation instructions for the verification plug Contents Installation ....................... 3 Connect verification plug ......................3 Seal the verification plug: ......................10 Complete the installation ......................10 Error report Err5......................... 10 How to connect the platform ............... 11...
  • Page 3: Installation

    Main circuit board E+ / Sen+ EXC+ Green SIG+ Shield White SIG- E- / Sen- Black EXC- Identchip Line colour Connect female Connect male main board IC GND Yellow 7: Identchip GND IC signal Brown 6: Identchip signal Open housing KIB-A12-IA-e-1910...
  • Page 4 Remove the CN8/power plug. Undo all cables Remove ferrite core KIB-A12-IA-e-1910...
  • Page 5 Pull cable through Reinsert sealing ring Attach both parts (see fig.) to the verification plug cable KIB-A12-IA-e-1910...
  • Page 6 Pull cable through and put on the cover cap Remove screws as shown in the diagram KIB-A12-IA-e-1910...
  • Page 7 Then solder the cable as shown in the wiring diagram (see chap. 1.1). Insert the board as shown in the diagram and secure with the 4 screws. KIB-A12-IA-e-1910...
  • Page 8 Reinsert the ferrite core Connect the cable as shown in the connection plan Connect the remaining cables to the board KIB-A12-IA-e-1910...
  • Page 9 Reconnect CN8 externally Close K1 jumper, K1 activates the verification plug. The verification plug does not function without K1. KIB-A12-IA-e-1910...
  • Page 10: Seal The Verification Plug

    The verification plug is finally configured correctly. 1.4 Error report Err5 Err 5 is shown if: • The verification plug is not connected correctly • The verification plug is defective • The wrong verification plug has been connected KIB-A12-IA-e-1910...
  • Page 11: How To Connect The Platform

    2 How to connect the platform • Disconnect the display unit from the power supply. • Solder the individual wires of the load cell cable to the printed circuit board It is necessary to ensure both soldering points J1 and J2 are always bridged. KIB-A12-IA-e-1910...
