- Page 1 Edition SC-PM 03.E SC Series Model SC-PM Instruction Manual SC-PMD Valid as of: 01.01.2013 • Please keep the manual for future reference!
-
Page 2: Table Of Contents
Contents 1 Warranty and liability ....................3 1.1 Notices within the instruction manual ..............3 1.2 Responsibilities of the operating company ............. 3 1.3 Responsibilities of the personnel ................3 1.4 Informal safety measures ..................4 1.5 Training of the personnel ..................4 1.6 Intended use ...................... -
Page 3: Warranty And Liability
Warranty: - SCHMIDT display units are warranted for 12 months. Parts subject to wear, electronic components and measuring springs are not covered by the warranty. No warranty or liability will be accepted for bodily injury or property damage resulting from one or several of the following causes: - Misuse or abuse of the device. -
Page 4: Informal Safety Measures
Hans Schmidt & Co GmbH. Any use with sensors from other manufacturers or any use exceeding this intention will be regarded as misuse. Under no circumstances shall Hans Schmidt & Co GmbH be held liable for damage result- ing from misuse. -
Page 5: General Information
General information 2.1 Specifications Digital display: Colour TFT 128 x 160 Units of measure: cN, daN, g, kg or lb (selectable) Damping (f 9-step adjustable Signal processing: Digital Measuring frequence: USB: 1 kHz RS-422: 200 Hz Output signal: Analog signal: 0 - 10 V DC (R >... -
Page 6: Pin Assignments Of Connectors And Cable
Hans Schmidt & Co GmbH. Certification to the CE specification does not extend to, and shall be invalid for any other combination. Under no circum- stances shall Hans Schmidt & Co GmbH be held liable for any damage result- ing from the use of non-SCHMIDT sensors or cables. -
Page 7: Connecting The Sc-Pm To Usb Or Can-Bus
2.4.1 Connecting the SC-PM to USB or CAN-Bus CAN-Bus (optional) Online Sensor Eearth +15 - 24 V DC 2.4.2 Connecting one SC-PM with the RS-422 interface The two 2 x 240 W terminating resistors must always be installed in the terminal block of the SC-PM-422. Terminating resistors 2 x 240 W Online Sensor... -
Page 8: Connecting Multiple Sc-Pm With The Rs-422 Interface
2.4.3 Connecting multiple SC-PM with the RS-422 interface The two 2 x 240 W terminating resistors must always be installed in the terminal block of the SC-PM-422. Abschlusswiderstände 2 x 240 W Unit max. 24 SC-PM Online Sensor Further units Unit 1 SC-PM Online... -
Page 9: Delivery Includes
Delivery includes SC-PM display unit 3 alligator clips USB cable instruction manual 2.5.1 Optional accessories Code CAN: CAN-bus interface Code A3: Current output 4 - 20 mA (0 - 10 V analog signal not applicable) All options must be factory fitted, re-fitting is only possible at the manufacturer‘s facility. EK0612 Connecting cable for TS sensor with 1 diode plug and open ends, length 3 m EK0614 Connecting cable for TS sensor with 1 diode plug and open ends, length 5 m EK0615 Connecting cable for TS sensor with 1 diode plug and open ends, length 10 m... -
Page 10: Operation
Operation 3.1 Operating elements TFT Display SET / GAIN key Plus key ESC / ZERO key Minus key USB interface fig. 3.1a Numeric display Info on material Current reading Measuring unit fig. 3.1b Min/Max alarm... - Page 11 3.1 Operating elements (cont.) Display with bargraph Info on material Current reading Current reading as bar graph Measuring unit Readings Min/Max alarm Tension range between the alarm values Graphic display Info on material Current reading Tension range Measured value Measuring unit as graph Readings length of the...
-
Page 12: Initial Setup
- Connect the SC-PM to the supplied sensor with one of the optional available cables. In no event shall Hans Schmidt & Co GmbH take over any warranty coverage for, or shall be held liable for, any damage resulting from self-made cables. - Page 13 3.3 Instrument settings (cont.) Main Menu Submenu Settings Menu Description To select a material characteristic curve to Material [1], [2], [3], [4] be used for a measurement. [character], To enter a name for the selected material Name [numbers], characteristic. [special character] Damp To adjust the damping factor for the (chapter...
- Page 14 3.3 Instrument settings (cont.) Main Menu Submenu Settings Menu Description [English], [Geman], Language [Spanish], Select between five user languages. [french], [Portuguese] If the lock is activated, no gain and zero [ON], [OFF] Lock adjustment can be performed. A white or black display background can Background [white], [black] be adjusted System...
-
Page 15: Operating Procedure
For example, eye protectors, gloves, etc. The ID plate with the CE mark and the serial number as well as the calibration label (optional) and the SCHMIDT Quality Seal are provided on the surface of the instrument. -
Page 16: Using The Alarm Function
3.4.2 Using the alarm function Requirements: A min. and max. limit value must be set in the “Material selection” menu for the mate- rial characteristic curve with which a measurement is to be conducted. Furthermore, the alarm must be activated in the “Material selection” menu. In addition, the alarm must be activated in the “Alarm”... -
Page 17: Sensor Calibration
All tension meters are calibrated with standard materials - such as polyamide monofila- ment (PA) - according to the SCHMIDT factory procedure; the material path is vertical. The corresponding diameter and material can be found in chapter 2 of the sensor. In the case of factory adjustment to the customer’s sample, the procedure is the same. -
Page 18: Zero And Gain Adjustment
3.5.1 Zero and gain adjustment You can save up to three different calibrations. The instrument is factory-set to material characteristic curve 1. This is the factory calibration, which should not be overwritten. Requirements: - Two weights, one corresponding to 10% and one to 90% of the selected tension range, must be provided. - Page 19 3.5.1 Zero and gain adjustment (cont.) Gain adjustment: Requirement: Zero adjustment carried out. To carry out gain adjustment: - Thread the process material through the measuring and guide rollers, following the red material path symbol on the front of the sensor. - Hang a weight that corresponds to e.g.
-
Page 20: Interfaces
- Save the adjusted values and exit the menu by pressing Digital interface 4.2.1 The »Tension Inspect 3« program The Tension »Inspect Software 3« from SCHMIDT is described in a separate user manual. 4.2.2 Windows terminal program The measured values can be transmitted to a personal computer. -
Page 21: Online Sensor Specifications
FS series (models FS1, FSP, FSR, FSH, FSL, FSW, FSB1) MZ series (models MAZD, MBZD, MAZF, MBZF, MBZB, MZ1, MZH, MZB1) Calibration: According to SCHMIDT factory procedure Accuracy: For 10% to 100% of range: TS: ± 1 % full scale FS: ±... -
Page 22: Service And Maintenance
Please indicate in your order whether you require an Inspection Certificate 3.1 according to DIN EN 10204. Service address: Hans Schmidt & Co GmbH Schichtstr. 16 D-84478 Waldkraiburg Germany... - Page 23 Notizen:...
- Page 24 Yarn Package Durometer and Shore Durometer Sample Cutter Balance Moisture Meter Leak Tester More than 75 years - Worldwide - Hans Schmidt & Co GmbH Mailing address: P. O. B. 11 54 Phone: e-mail: 84464 Waldkraiburg Germany int. + 49 / (0)8638 / 9410-0 info@hans-schmidt.com...
