Page 1
5 Safety information Know your device How to insert Micro-SIM card and connect the battery Gently remove MSP500 cover using plastic pry tool from both sides. Insert Micro-SIM card as shown with PIN request disabled or read Security info how to Configurator.
Page 2
Ground PIN for USB Wiring scheme For the more detailed MSP500 device wiring, see the scheme below. PC Connection (Windows) Power-up MSP500 with DC voltage 10-30 V power supply using supplied power cable. “MSP500 LED status”. LED’s should start blinking, see...
Page 3
Configuration (Windows) At first MSP500 device will have default factory settings set. These settings should be changed according to the user's needs. Teltonika Configurator Main configuration can be performed via software. Get the latest MSP500 Configurator version from here. Configurator operates on Microsoft Windows OS and uses prerequisite MS .NET Framework.
Page 4
Maintenance and etc. MSP500 has one user editable profile, which can be loaded and saved to the device. After any modification of configuration the changes need to be saved to device using Save to device button. Main buttons offer following functionality: Load from device –...
Page 5
If device has made a record it is sent to the server every 120 seconds After successful SMS configuration, MSP500 device will synchronize time and update records to configured server. Time intervals and default I/O elements can be changed by using Teltonika Configurator parameters.
Page 6
Teltonika is not responsible for any harm caused by wrong cables used for connection between PC and MSP500. WARNING! Do not use MSP500 device if it distracts driver or causes inconvenience due to OBD II placement. Device must not interfere with driver.
