  • Page 1 MTB100 Quick Manual v1.2 Track & trace device...

  • Page 2: Table Of Contents

    How to install USB drivers (Windows) ..........7 Configuration (Windows) ..............7 Quick SMS configuration ..............9 Mounting recommendations ............. 10 LED indications ................11 Characteristics................11 Basic characteristics ............... 11 Electrical characteristics ..............13 Safety information ..............14 Certification and Approvals ............15 Wiki MTB100 |...

  • Page 3: Know Your Device

    Know your device Figure 1 MTB100 device view Wiki MTB100 |...

  • Page 4: Pinout

    Pinout Table 1 MTB100 pinout PIN NUMBER PIN NAME DESCRIPTION (6-30) V DC (+) Power supply (6-30) V DC (+) GND (-) Ground pin Digital input, channel 1. DEDICATED DIN 1 FOR IGNITION INPUT Analog input, channel 1. Input range: 0-...

  • Page 5: Wiring Scheme

    Wiring scheme Figure 3 MTB100 Wiring scheme Automotive relay Wiki MTB100 |...

  • Page 6: Set Up Your Device

    Set up your device How to insert Micro SIM card and connect the battery 1. Gently remove MTB100 cover using plastic pry tool from both sides. 2. Insert Micro-SIM card as shown with PIN request disabled or read Security info how to enter it later in Configurator.

  • Page 7: Pc Connection (Windows)

    5. Setup will continue installing the driver and eventually the confirmation window will appear. Click Finish to complete the setup. 1. Power-up MTB100 with DC voltage 6-30 V power supply using power cable. LED’s should start blinking, see “LED indications”. Configuration (Windows) 2.
  • Page 8 Most important configurator section is GPRS – where all your server and GPRS settings can be configured and Data Acquisition – where data acquiring parameters can be configured. More details about MTB100 configuration using Configurator can be found in our Wiki. Figure 10 Configurator Status window Wiki MTB100 |...

  • Page 9: Quick Sms Configuration

    • server every 120 seconds 2005 – Port • After successful SMS configuration, MTB100 device will 2006 – Data sending protocol • synchronize time and update records to configured server. (0 – TCP, 1 – UDP) Time intervals and default I/O elements can be changed by using...

  • Page 10: Mounting Recommendations

    ▬ When the module is connected, measure the voltage again to make sure it did not decrease. ▬ It is recommended to connect to the main power cable in the fuse box. ▬ 3 A, 125 V external fuse shall be used. Wiki MTB100 |...

  • Page 11: Led Indications

    Quad-band 850 / 900 / 1800 / 1900 2G bands GPRS Multi-Slot Class 12 (up to 240 Data transfer kbps), GPRS Mobile Station Class B Data support SMS (text/data) Expected time in conditions with good GNSS satellites visibility Wiki MTB100 |...
  • Page 12 GPS, NITZ, NTP PHYSICAL SPECIFICATION Fuel monitoring LLS (Analog), OBDII dongle Dimensions 79 x 43 x 27.5 mm (L x W x H) Digital Input 1, Accelerometer, External Power Voltage, Engine RPM (OBDII Ignition detection Weight 69 g dongle) Wiki MTB100 |...

  • Page 13: Electrical Characteristics

    Drain-Source clamp threshold voltage, Input resistance (DIN1) kΩ = 2 mA) drain Input voltage (Recommended Operating Supply Digital Input Voltage Conditions) voltage Analog Input Voltage Input Voltage threshold (DIN1) Analog Input error margin can increase if temperature varies. Wiki MTB100 |...

  • Page 14: Safety Information

    Dispose of used batteries the requirements of EN 60950-1 standard. according to the instructions. The device MTB100 is not designed as a navigational device for boats. • Battery should not be disposed of with general Do not disassemble the device. If the device is household waste.

  • Page 15: Certification And Approvals

    This sign on the package means that all used electronic and electric equipment should not be mixed with general household waste. Hereby, Teltonika declare under our sole responsibility that the above described product is in conformity with the relevant Community harmonization: European Directive 2014/53/EU (RED).

  • Page 16: Warranty

    More information can be found at teltonika.lt/warranty-repair • Repaired • Replaced with a new product • Replaced with an equivalent repaired product fulfilling the same functionality • TELTONIKA can also repair products that are out of warranty at an agreed cost. Wiki MTB100 |...
