  • Page 1 Handheld GPS/GSM Tracker GH1201 User Manual v1.10...

  • Page 2: Table Of Contents

    6.3 SOUND INDICATION..........................14 SPECIAL SMS REQUESTS ......................... 15 TRACK ASSISTANT SOFTWARE......................18 8.1 TRACK ASSISTANT CONFIGURATION TOOL .................18 8.1.1 CONFIGURATION OF GH1201 USING A PC ..............18 8.1.2 PIN CODE..........................23 8.2 TRACK ASSISTANT MONITORING TOOL ..................23 MAINTENANCE AND REPAIR ......................30...

  • Page 3: Preface

    1. PREFACE INTRODUCTION GH1201 is a device with built-in functions characteristic of a mobile phone and an integrated GPS receiver. This device is intended for the surveillance and protection of people, cargo and objects. The GPS receiver may define the current location of the device and sends this data to a person in charge or the operation centre.
  • Page 4 Handheld GPS/GSM Tracker GH1201 User Manual v1.10 FOR YOUR SAFETY Please read these basic explanations. In disregarding them you may face danger or trespassing of existing laws. In case you wish to have more information, please read the concise user manual.
  • Page 5 Power supply chains available at a place used for connecting GH1201 must have safety devices (automatic bipolar switch off devices) which protect from power supply excess, short circuit and failure of grounding.
  • Page 6 Handheld GPS/GSM Tracker GH1201 User Manual v1.10 Household socket Protect. grounding Electricity Phase-wire distributing board 230 V Zero-wire Automatic switch off device USB connection GH1201 Charger 230-5V USB cable SAFELY DISCONNECT THE DEVICE The device may be disconnected from the PC or charger by pulling out the USB connection from the computer USB socket or by pulling out the mini USB connection from GH1201.

  • Page 7: General Information

    User Manual v1.10 2. GENERAL INFORMATION 2.1 PACKAGE CONTENT GH1201 is supplied to the client packed in a cardboard box with all supplements that are necessary for operation. The set consists of: Handheld GPS/GSM Tracker GH1201 Li-Ion or Li-Pol 750mAh battery 3.7V USB –...

  • Page 8: Electronic Specifications

    Handheld GPS/GSM Tracker GH1201 User Manual v1.10 2.3 ELECTRONIC SPECIFICATIONS Parameter Norm Supply voltage (DC) 4.5V 5.5V Use of electric current 360mA 2500mA (10ms) Battery voltage (DC) 3.7V 4.2V Charger voltage (DC) 4.5V 5.5V Charger electric current 600mA 1000mA...

  • Page 9: Getting Started

    Handheld GPS/GSM Tracker GH1201 User Manual v1.10 3. GETTING STARTED 3.1 INSERTING SIM CARD AND BATTERY All SIM cards must be kept in a save place. You may request your SIM card supplier to provide SIM cards and information about the use of SIM card-related services. The supplier may be a service supplier, a network operator or another seller.

  • Page 10: Charging The Battery

    Plug the charger in the alternating current wall socket. After the device is connected to the PC or alternating current wall socket, the battery charging will start. Charging is indicated by the indicator which is present on the GH1201 (see Indicators of the device).

  • Page 11: Installing Software

    Track Assistant Software should you fail to find it, try downloading it from the official website: www.teltonika.eu. Insert the CD available within the set into the CD driver. The installation of the software starts by activating the Setup.exe file available in the catalogue ...\Drivers Installation Files\Setup.exe...

  • Page 12: Getting To Know The Handheld Gps/Gsm Tracker

    Before connecting the device to the PC it is recommended to install Track Assistant program at first. When the software installed, GH1201 can be connected to a stationary or portable computer by using an USB data cable. Please wait until the computer detects the new device and it will switch on automatically.

  • Page 13: Device Indicators

    Handheld GPS/GSM Tracker GH1201 User Manual v1.10 6. DEVICE INDICATORS 6.1 INDICATING THE STATUS If you wish to correctly find out the parameters under which the device operates, observe as carefully as possible the status of the three indicators. Each status indicator consists of 2-coloured lamps - one of which is indicating a...

  • Page 14: Indicating A Button Push

    User Manual v1.10 6.2 INDICATING A BUTTON PUSH If GH1201 is in standby mode you can check if the device is powered with a short button push. The standby check is possible with each button on the keyboard. If the device is powered, the Battery LED will lighten green.

  • Page 15: Special Sms Requests

    INF! Id:GH-1201 Imei:35397601XXXXXXX Time: YYYY.MM.DD HH:MM:SS Version:HH_1.X.X.X CF:1 Live:21511 Op:24602 Cell:030B Sig_Lvl:32 Bat_Lvl:94 – GH1201 will check in which Geofence zone1 it is and if it is inside - will send the Geofence zone GEO? name. Device is in the Zone(s)
  • Page 16 – NAVIGON2 Mobile Navigator 6 ® (Version 6.3 or higher). After receiving such a SMS GH1201 will send back a SMS to the Mobile Phone and you will be able to see the GH1201 position within the NAVIGON software (on the NAVIGON Map).
  • Page 17 Handheld GPS/GSM Tracker GH1201 User Manual v1.10 Notification about Battery Level When the function Send Notification about Battery Level is activate you will be informed depends of configuration is chosen via SMS message about the level of the battery. BAT! Id:GH1201...

  • Page 18: Track Assistant Software

    8.1.1 Configuration of GH1201 Using a PC Please start the Track Assistant Configuration Tool. After GH1201 has been connected to the PC the battery LED will start flashing in green. Click the button...
  • Page 19 (format +441234567890). If this function has been activated, it will protect GH1201 from unwelcome queries via SMS (i.e. Fix?, Inf? Geo? etc.) by external persons without authorization. If the list of authorised numbers is not...
  • Page 20 Keyboard this function by clicking on the respective about incoming or outgoing SMS messages. button on your GH1201. Please view the Choose the ringing tone of the device and set section “Indicating a button push” in this the levels of the ring...
  • Page 21 Handheld GPS/GSM Tracker GH1201 User Manual v1.10 When you open the Alarm window you can You can fix the automatic data update interval insert up to five SMS numbers to send Alarm (GPS Logging Interval). If this function has Messages. In parallel a call to one phone...
  • Page 22 Send Through SMS the device. (Teltonika) GSM Modem is connected to your PC. If this option is selected the program will send all configuration changes to the GH1201 device via SMS. Click the button Finish. If you have chosen Send Through SMS...

  • Page 23: Pin Code

    Stored GPS Data can be reviewed directly from GH1201 (with the USB cable) and can be shown on the map. You can store or export the data.
  • Page 24 Handheld GPS/GSM Tracker GH1201 User Manual v1.10 8.2.2 The Monitoring Tool. General View The tool consists of five information windows (3, 4, 5, 8, 9) and four configuration tools (1, 2, 6, 7). Sytem tools menu Image menu User profiles...
  • Page 25 Handheld GPS/GSM Tracker GH1201 User Manual v1.10 Connect ... – connect the device to the Monitoring Tool Device Info – review the information about the device Connect Modem – connect a Modem to the Track Assistant Monitoring Tool Options ... Ctrl+O –...
  • Page 26 Here, you will be able to view the information about the current device status, no matter if it is a Modem or GH1201. If the device connected to the system, you will be able to see the message Device Connected,...
  • Page 27 Handheld GPS/GSM Tracker GH1201 User Manual v1.10 When the track contains too many points an Error warning will appear. If an error window (as shown in figure above) appears during data transfer, you can click to resolve the issue. Upon clicking, you will have two options. These options will help to optimize the data history. The...
  • Page 28 Now the zone will be deleted and can be created again. 5 – Confirm the selection of the zone (Done) 6 – Save the updates into GH1201 or send the settings via SMS message by clicking the button Write to Device if a GSM Modem is connected.
  • Page 29 Handheld GPS/GSM Tracker GH1201 User Manual v1.10 SMS format is: The number „1“ shows what your device came in the CROSS! Id:GH-1201 Imei: 35397601XXXXXXX Time: YYYY.MM.DD zone. The number „0“ shows that your device left the HH:MM:SS Fix: 54.1215, 25.1324 Sat:6 zone.

  • Page 30: Maintenance And Repair

    The sign on the packaging means that the electric and electronic equipment to be utilised must be stored separately. In case you have problems with the use of the product beyond your possibilities to solve it, please address them to the Technical Assistance Centre by e-Mail support@teltonika.lt.
  • Page 31 Handheld GPS/GSM Tracker GH1201 User Manual v1.10 10. NOTES Date Comments...

  • Page 32: Declaration Of Conformity

    Are in conformity with the following EC Directives, including all amendments: R&TTE Directive 1999/5/EC Standards applied: 3GPP TS11.10-1 rel99 Expert Opinion (for Teltonika GSM/GPRS module TM2), No: P251-0158/06, Slovenian Institute of Quality and Metrology (notified body’s identification number 1304), Ljubljana, Slovenia LVD Directive 2006/95/EC Standards applied: IEC 60950-1:2001, modified Test report No: 950-1.16-07E, Testing Centre UAB Ratesta, Kaunas, Lithuania...
