Table of Contents

Advertisement

Quick Links

Download this manual
https://wiki.teltonika-gps.com/view/Speed_Limiting_Solution_MSP500%2BETC
Speed Limiting Solution MSP500+ETC
Main Page
>
General Information
MSP500+ETC
Contents
1 Introduction
2 Solution description
10 Demonstration in Wialon platform
11 Demonstration in Flespi platform
12 Demonstration in TAVL platform
Introduction
Due to the accidents caused by over speeding, corporate fleet businesses and insurance companies
suffer from huge losses in most of the countries globally. This can often lead to a loss in productivity,
reduction in revenue, paying insurance costs (if it's the driver's fault), as well as medical and
collateral damage costs. To help resolve this major concern, here at Teltonika Telematics we have
developed and manufactured a unique GPS tracker with the speed limiter feature.
Solution description
Utilizing a modern and comprehensive GPS tracking method allows you to monitor driver (including
novice) behaviour, improve safety, and reduce the fleet running costs and legal liability. And that is
where Teltonika MSP500 comes into the play.
>
Usage scenarios
>
Speed Limiting Solution
> Speed Limiting Solution

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MSP500+ETC and is the answer not in the manual?

Questions and answers

Related Manuals for Teltonika MSP500+ETC

Summary of Contents for Teltonika MSP500+ETC

  • Page 1: Table Of Contents

    (if it’s the driver’s fault), as well as medical and collateral damage costs. To help resolve this major concern, here at Teltonika Telematics we have developed and manufactured a unique GPS tracker with the speed limiter feature.

  • Page 2: What You Need For A Solution

    Teltonika MSP500 is a special tracking terminal with GNSS/GSM/Bluetooth 4.0 connectivity, internal GNSS/GSM antennas, RS232 interface, internal Ni-Mh battery, and waterproof IP65 casing. The device has been specifically designed with the key feature – speed limiting control. What you need for a solution? MSP500 device.

  • Page 3: Etc Connection With Msp500

    S+/0.70V from ECU Grey S-/0.40V from ECU Note: Voltage may vary depending on vehicle model. https://wiki.teltonika-gps.com/view/File:ETC.mp4 In this tested vehicle. Voltages of the connections between ECU and Accelerator Pedal are (+) 0.49V and (-) 0.25V. 2. ETC connection with MSP500: Use a cable extension (optional) to connect ETC with MSP500.
  • Page 4 After successful GPRS/SERVER settings configuration, MSP500 device will synchronize time and update records to the configured server. Time intervals and default I/O elements can be changed by using Teltonika Configurator parameters. Sleep settings: 102 – Sleep settings(0 – Disable, 1 – Gps sleep, 2 – Deep sleep, 3 – Online Deep sleep, 4 – Ultra...
  • Page 5 Over speeding settings 11100 – Scenario settings (0 – Disable, 1 – Low Priority, 2 – High Priority (Default), 3 – Panic Priority) 11104 - Max Speed (Default value - 90 km/h), here we tested on 40 km/h 13217 - Speed Source (0 - GNSS (Default), 1 - OBD, 2 - AIN1) In case of AIN1, if you use only A2 - the formula would look like Speed = A2 * Pulses 13223 - Over speeding Hysteresis (Default value - 8%), value that determines what would be the threshold speed level that would activate the speed limiting feature...

  • Page 6: Testing

    Quickstart: From default configuration to Speed Limiting solution in one SMS: " setparam 2001:APN;2002:APN_user;2003:APN_password;2004:Domain;2005:Port;2006:0;102:3;1 1100:2;11104:40;13217:0;13223:8;11103:1" This SMS will set up your device to report the Speed Limiting scenario to the server. Note: Before SMS text, two space symbols should be inserted if no SMS username or password was set in SMS \ Call settings.

  • Page 7: Parsing Information

    40 km/h. Parsing information 1. Prerequisites: 1.1. Open TCP/UDP port 1.2. Read Java parser first start guide 2. Parsing example: Unparsed received data in hexadecimal stream 000000000000005E8E010000017DE72C308A012100F6F60EF8A0FE0000008F0A002900FF0010000700EF0100F00100150200C80000450101F60000FF29000500B5 000F00B60008004238D500431F5000440027000200F10000A5A200100000BF7B000000000100006D90 AVL Data Packet Part HEX Code Part Zero Bytes 00 00 00 00 Data Field Length 00 00 00 5E Codec ID...
  • Page 8 Flespi: Open Flespi application → Select Device → Select Logs & Messages → Select the record interval → Tap to see all information. https://wiki.teltonika-gps.com/view/File:Flespi.mp4 Demonstration in TAVL platform TAVL: Open TAVL application → Select Client → Select Device → Select the date interval → Select...
  • Page 9 Speed limiting is activated when max speed is exceeded. Relay is activated on DOUT1 which can either disable the acceleration pedal, turn off the fuel pump or close the solenoid valve. Only one scenario can be used per MSP500 device.
