  • Page 1 FMB125 Quick Manual Dual-SIM tracker with v1.4 RSR232, RS485 interfaces...

  • Page 2: Table Of Contents

    How to install USB drivers (Windows) ..........7 Configuration (Windows) ..............7 Quick SMS configuration ..............9 Mounting recommendations ............. 10 LED indications ................11 Characteristics................11 Basic characteristics ............... 11 Electrical characteristics ..............13 Safety information ..............14 Certification and Approvals ............15 Wiki FMB125 |...

  • Page 3: Know Your Device

    Know your device Figure 1 FMB125 device view Wiki FMB125 |...

  • Page 4: Pinout

    Pinout Table 1 FMB125 2x6 socket pinout PIN NUMBER PIN NAME DESCRIPTION VCC (10-30)V DC (+) Power supply (+10-30 V DC). Analog input, channel 1. Input range: AIN 1 0-30 V DC. RS232 – RX Input for data receive through RS232 Output for data transmit through RS232 –...

  • Page 5: Wiring Scheme

    Wiring scheme Figure 3 FMB125 Wiring scheme Automotive relay Wiki FMB125 |...

  • Page 6: Set Up Your Device

    Set up your device How to insert SIM card and connect the battery 1. Gently remove FMB125 cover using plastic pry tool from both sides. 2. Insert SIM card as shown with PIN request disabled or read Wiki how to enter it later in Teltonika Configurator.

  • Page 7: Pc Connection (Windows)

    Setup will continue installing the driver and eventually the confirmation window will appear. Click Finish to complete the setup. 1. Power-up FMB125 with DC voltage (10 – 30 V) power supply using supplied power cable. LED’s should start blinking, see Configuration (Windows) “LED indications”.
  • Page 8 Most important configurator section is GPRS – where all your server and GPRS settings can be configured and Data Acquisition – where data acquiring parameters can be configured. More details about FMB125 configuration using Configurator can be found in our Wiki. Figure 10 Configurator Status window Wiki FMB125 |...

  • Page 9: Quick Sms Configuration

    • server every 120 seconds 2005 – Port • After successful SMS configuration, FMB125 device will 2006 – Data sending protocol • synchronize time and update records to configured server. (0 – TCP, 1 – UDP) Time intervals and default I/O elements can be changed by using Teltonika Configurator parameters.

  • Page 10: Mounting Recommendations

    Depending on the car model, this may happen in 5 to 30 minutes period. ▬ When the module is connected, measure the voltage again to make sure it did not decrease. ▬ It is recommended to connect to the main power cable in the fuse box. Wiki FMB125 |...

  • Page 11: Led Indications

    Device is not working or Device is in Technology boot mode Quad-band 850 / 900 / 1800 / 1900 2G bands GPRS Multi-Slot Class 12 (up to 240 Data transfer kbps), GPRS Mobile Station Class B Data support SMS (text/data) Wiki FMB125 |...
  • Page 12 Adapters, OBDII dongle) Log Mode, NMEA, LLS, LCD, RFIH Dimensions 65 x 56,6 x 20,6 mm (L x W x H) RS232 HID/MF7, Garmin FMI, TCP SCII/Binary Weight 55 g RS485 Log Mode, NMEA, LLS, TCP SCII/Binary Wiki FMB125 |...

  • Page 13: Electrical Characteristics

    Additional error on 30 V, Range 2 Input voltage (Recommended Operating Supply Conditions) voltage OUTPUT SUPPLY VOLTAGE 1-WIRE Input Voltage threshold (DIN1) Supply voltage +4.5 +4.7 Output inner resistance Ω Output current (U > 3.0 V) Short circuit current (U = 0) Wiki FMB125 |...

  • Page 14: Safety Information

    EN 60950-1 standard. according to the instructions. The device FMB125 is not designed as a navigational device for boats. Battery should not be disposed of with general Do not disassemble the device. If the device is household waste.

  • Page 15: Certification And Approvals

    00647‐20‐08591 FMB125 RoHS • website www.anatel.gov.br FMB125 Declaration of device operation temperature • This equipment is not entitled to protection against harmful interference and must not This sign on the package means that it is cause interference in duly authorized necessary to read the User‘s Manual before...

  • Page 16: Warranty

    More information can be found at teltonika.lt/warranty-repair • Repaired • Replaced with a new product • Replaced with an equivalent repaired product fulfilling the same functionality • TELTONIKA can also repair products that are out of warranty at an agreed cost. Wiki FMB125 |...
