Electrical Connection - TEKNIX TKED64INDB Instruction Manual

Installing your Freestanding Cooker
Fitting a Power Supply Cable
Icon Type
WARNING:
WARNING: Installation MUST ONLY
WARNING
be carried out by a qualified approved
installer, ie. an Electrician.
RISK OF ELECTRIC SHOCK
Connecting appropriate power supply
SYMBOL ISO 7010 W021
' terminal board/ connector block':
WARNING:
CAUTION
REFER to TECHNICAL table at the
IMPORTANT / NOTE
rear of this manual for correct rating
for your corresponding model
WARNING:
purchased.
1. SAFETY INSTRUCTIONS WARNING:
1. Using a screwdriver, prize open tabs
of the Terminal board cover.
2. Remove the wire clamp screw.
1.1 General Safety Warnings
3. Fasten the wires beneath the
corresponding screw heads, using
brass 'bridge' for single phase supply.
4. Fasten cable clamp and close the
cover of the terminal board.
5. The AC power supply should be
220-240V or 380-415V, 50-60Hz.
WARNING: WARNING: Connect the power cord
must be in accordance with the
instructions listed in the table below:
WARNING:
Wire cross-sectional area
(mm 2 ) connection mode
220-240V 1N~
380-415V 3N~
WARNING:
WARNING:
EN - 2
EN - 4
L1 L2
4 mm -
2
Min 2.5 Min 2.5
EN - 4
Meaning
Serious injury or death risk
Dangerous voltage risk
L3
-
Min 2.5
12
N E
4 mm 4 mm
2 2
Min 2.5 Min 2.5
