Care and maintenance

Replacing the oven lamps

Disconnect the oven from the power supply at the fuse-box by means of the
switch used to connect the appliance to the electrical mains ;or unplug the
appliance.
Remove the glass cover of the lamp-holder by rotating
anti-clockwise.
Remove the lamp and replace with a lamp resistant to high
temperatures (300℃) with the following characteristics:
Voltage: 220-240V
Wattage: 25W
Type: G9(Halogen lamp)
Energy e ciency class: G
Replace the glass cover. Reconnect the appliance to the mains power supply.
Cleaning the oven door / How to remove the oven doors
For a more thorough clean, you can remove and disassemble the oven door.
Proceed as follows:
Oven door removal and assemble procedure:
Open the door to the full extent (fig.1)
Open the lever A completely on the left and right hinges (fig.2).
Hold the door as shown in (fig.3).
Gently close the door (fig.3) until left and right hinge levers A are hooked to part
B of the door (fig.4).
Withdraw the hinge hooks from their location following arrow C ( fig.4).
Rest the door on a soft surface.
To replace the door, repeat the above steps in reverse.
Fig.1
Fig.2
29
Fig.3
Fig.4
