Electrical Connection - TEKNIX TKRC100B Installation & User's Instructions

Installation

Electrical connection

IMPORTANT: Electrical connections
must be carried out by a suitably
qualified person and in accordance with
all relevant local building and installation
regulations.
1. See the rating label at the rear of the product for
the appliance's load rating.
2. The cooker must be connected to a dedicated
circuit suitably rated for the load of the appliance
(see rating label at rear of appliance) as shown in
the wiring diagrams below. It must be connected
via a suitably rated cable to a double pole isolator
cooker switch also suitably rated for the appliance.
3. The electrical cable should not touch the
hot parts of the appliance.
The electrical cable (not supplied)
should not be routed through any
area that may be affected by heat from
the oven, especially the area directly
behind the oven.
3x6mm
2
3x6mm
2
8
