S P E C I F I C A T I O N S
Physical Dimensions
Size: 8.8 in. x 4 in. x 1.25 in.
Weight (including batteries): 1 lb. 2 oz.
Power
AC adapter: 9VDC, 200 mA (barrel is positive)
Batteries: 5 user-replaceable, NiCad, AA rechargeable
Keyboard
57 keys in 5 rows; Control plus 15 function keys
Character set: A-Za-z0-9!'"$()+=?,. and special
characters
Display
Backlit, liquid crystal
Two 40-character lines

FCC Information

The Compact/C has been tested and found to comply
with the specifications for a Class B digital device
pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates and uses radio frequency energy
and if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to
radio or television reception, which can be determined
by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or
more of the following measures:
Connections
3.5 mm audio jack for connection to compatible
cellular and cordless phones
Acoustic Coupler
Accepts both circular and square telephone handsets
Communication Codes
Baudot code:
45.5-baud or 50-baud
Output: 100 dBSPL (min)
Turbo Code:
100 baud (average)
7 data bits
• Reorient or relocate the receiving antenna.
• Increase the separation between the Compact/C
and the receiver.
• Connect the Compact/C to an outlet on a circuit
different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV
technician for help.
Should you experience trouble with this TTY
equipment, please contact:
Ultratec National Service Center
5901 Research Park Blvd.
Madison, WI 53719
email: service@ultratec.com
For repair or warranty information, please contact
Ultratec Inc. Customer Service at (608) 238-5400
Memory
32K (approximately 32,000 characters)
Non-volatile
Stores unlimited Memos and Directory entries (total of
9.5K)
Stores recent TTY Conversations (22K)
Records Conversations to Memos
Memory edit functions: search, insert, delete, clear
(V/TTY). If the equipment is causing harm to the
telephone network, the telephone company may
request that you disconnect the equipment until the
problem is resolved.
Other than replacing the batteries, the Compact/C
does not have any user-serviceable parts. Modification
or changes to the Compact/C not expressly approved
by Ultratec, Inc. can void your authority to operate the
TTY.
28
