Crestron UC-MX70-NC-Z Quick Start Manual

UC-MX70-NC-Z
Crestron Flex Advanced Tabletop Large Room Conference System for Zoom Rooms® Software
The UC-MX70-NC-Z Crestron Flex advanced tabletop conferencing
system provides a large room conference solution for use with Zoom
Rooms® software. It supports up to three video displays and features a
Crestron Flex tabletop conference device and UC bracket assembly.
Minimum Requirements:
A Zoom Rooms certified USB Camera (not included).
l
A video display (not included) connected to the UC Engine. A second
l
display is optional.
A Zoom Rooms account or activation code (not included).
l
In the Box
Tabletop Conference Device
1 Tabletop Conference Device, Zoom Rooms Software
(6510610)
1 Cable, CAT5e, RJ-45 - RJ-45, 12 ft (3.7 m) (2033988)
1 Cable Retention Plate (2047908)
1 Power supply (2045873) with cord (2042043)
3 Tie Wrap (2047935)
UC Bracket Assembly
1 UC Bracket Assembly with UC Engine and HDMI® or AV
over CAT5 content ingest (UC-BRKT-260-P-Z-ASSY,
6512692)
2 Anchor, Drywall, Plastic, 3/8 in. x 1/2 in. (9.5 mm x
12.7 mm) (2052565)
1 Key, Anchor (4529654)
1 Power pack (2045870)
2 Screw, 8-AB x 1-1/2 in. (38.1 mm), Pan Head, Combo
(2052567)
4 Tie Wrap (2047935)
Additional Items
1 Microphone pod (6508084)
2 Cable, CAT6a, RJ-45 - RJ-45, 20 ft (6.1 m) (6507640)
1 Cable, CAT5e, RJ-45 - RJ-45, 7 ft (2.1 m) (6509924)
1 Cable, DisplayPort™ to HDMI, 6 ft (1.8 m) (6508282)
1 Cable, thin HDMI®, 6 ft (1.8 m) (6510946)
1 Cable, HDMI, 6 ft (1.8 m) (6512150)
1 Cable, USB 2.0, A - Micro-B, 6 ft (1.8 m) (6510947)
Quick Start
1
