UC-MX70-NC-T
Crestron Flex Advanced Tabletop Large Room Conference System for Microsoft Teams® Rooms
The UC-MX70-NC-T Crestron Flex advanced tabletop conferencing
system provides a large room conference solution for use with Microsoft
Teams® Rooms software. It supports single or dual video displays and
features a Crestron Flex tabletop conference device and UC bracket
assembly.
Minimum Requirements:
A Microsoft Teams certified USB Camera (not included).
l
A video display (not included) connected to the UC Engine. A second
l
display is optional.
A Microsoft Teams Rooms provisioned account (not included).
l
In the Box
Tabletop Conference Device
1
Tabletop Conference Device, Microsoft Teams video
(6511747)
1
Cable, CAT5e, RJ-45 - RJ-45, 12 ft (3.7 m) (2033988)
1
Cable Retention Plate (2047908)
1
Power supply (2045873) with cord (2042043)
3
Tie Wrap (2047935)
UC Bracket Assembly
1
UC Bracket Assembly with UC Engine and HDMI® or AV
over CAT5 content ingest (UC-BRKT-260-P-T-ASSY,
6512691)
2
Anchor, Drywall, Plastic, 3/8 in. x 1/2 in. (9.5 mm x
12.7 mm) (2052565)
1
Key, Anchor (4529654)
1
Power pack (2045870)
2
Screw, 8-AB x 1-1/2 in. (38.1 mm), Pan Head, Combo
(2052567)
4
Tie Wrap (2047935)
Additional Items
1
Microphone pod (6508084)
2
Cable, CAT6a, RJ-45 - RJ-45, 20 ft (6.1 m) (6507640)
1
Cable, CAT5e, RJ-45 - RJ-45, 7 ft (2.1 m) (6509924)
1
Cable, DisplayPort™ to HDMI, 6 ft (1.8 m) (6508282)
1
Cable, thin HDMI®, 6 ft (1.8 m) (6510946)
1
Cable, HDMI, 6 ft (1.8 m) (6512150)
1
Cable, USB 2.0, A - Micro-B, 6 ft (1.8 m) (6510947)
Quick Start
1

Advertisement

Table of Contents
loading

Related Manuals for Crestron UC-MX70-NC-T

Summary of Contents for Crestron UC-MX70-NC-T

  • Page 1 Quick Start UC-MX70-NC-T Crestron Flex Advanced Tabletop Large Room Conference System for Microsoft Teams® Rooms The UC-MX70-NC-T Crestron Flex advanced tabletop conferencing Screw, 8-AB x 1-1/2 in. (38.1 mm), Pan Head, Combo system provides a large room conference solution for use with Microsoft (2052567) Teams®...

  • Page 2: Mount Devices

    Quick Start UC-MX70-NC-T Crestron Flex Advanced Tabletop Large Room Conference System for Microsoft Teams® Rooms Mount Devices Mount the UC Bracket Assembly Mount the UC Bracket Assembly to VESA® compliant display devices, a wall, or other building structure. Anchors and screws are supplied for installation on walls with 3/8 in.

  • Page 3: System Overview

    Quick Start UC-MX70-NC-T Crestron Flex Advanced Tabletop Large Room Conference System for Microsoft Teams® Rooms Connect System Overview When connections are complete, the system appears as shown below. Refer to Make Connections for detailed connection instructions.

  • Page 4: Make Connections

    Quick Start UC-MX70-NC-T Crestron Flex Advanced Tabletop Large Room Conference System for Microsoft Teams® Rooms Make Connections 1. Make UC Engine connections as shown in the following illustrations. The conference device can communicate with the UC Engine over a direct connection or a network connection. Select one of the connection types as described below.
  • Page 5 Quick Start UC-MX70-NC-T Crestron Flex Advanced Tabletop Large Room Conference System for Microsoft Teams® Rooms Make a network connection if the system is to be managed by the XiO Cloud® service. NOTE: When a network connection is used, disconnect the direct connect adapter from the UC Engine.
  • Page 6 Quick Start UC-MX70-NC-T Crestron Flex Advanced Tabletop Large Room Conference System for Microsoft Teams® Rooms 2. Make a network or direct connection on the bottom of the conference device as described in step 1. Make the remaining content ingest, laptop, mic pod, and power connections. Connect the conference device's power supply to an AC power outlet.
  • Page 7 Quick Start UC-MX70-NC-T Crestron Flex Advanced Tabletop Large Room Conference System for Microsoft Teams® Rooms 3. Connect the power supply and camera (not included) to the bottom of the content ingest device (HD-CONV-USB-260). Connect the power supplies to an AC power outlet.

  • Page 8: Apply Power

    Quick Start UC-MX70-NC-T Crestron Flex Advanced Tabletop Large Room Conference System for Microsoft Teams® Rooms 3. Enter the following information in the appropriate fields: Teams Video PC Address: Enter the IP address or hostname of the UC Engine. Configure NOTE: The hostname is printed on a label affixed to the UC Engine.
  • Page 9 Development Tools License Agreement. Crestron product operating system software is licensed to Crestron dealers, CSPs, and end-users under a separate End-User License Agreement. Both of these Agreements can be found on the Crestron website at www.crestron.com/legal/software_license_agreement. The product warranty can be found at www.crestron.com/warranty.
