Premio OSS424-UN Quick Manual

Thank you for your purchase of Premio OSS424-UN Storage Server System!
1.
Check the Content
your package contains the following:
# Description
1 OSS424-UN
Enclosure
2 Motherboard
3 CPU and memory
4 IO Cards
5 Heatsink
6 2x 2.5" Drive Bay
7 8x 2.5" Drive Bay
8 Slide Rail Kit + Screws
9 Power Cable*
10 Serial Cable*
* Inside the accessories box. Box may consist of screw sets for rail kit or
drives. If any items are missing, please contact your reseller or sales rep.
2.
Get Familiar with the Unit.
OSS424-UN is a storage server supporting single AMD EPYC
processor and front tray-less 24x 3.5" HDDs, optional rear 2x
or 8x 2.5" drive bays powered by Gigabyte MZ31
motherboard.
Front view of the unit
Rear view of the unit
Installation and service of this product should be conducted by a trained
personnel to avoid bodily injury from electric shock or heavy object
OSS424-UN Quick Guide
Version 1.00 – 2017.10.23
of the box. Please confirm that
Image / Description
Gigabyte MZ31-AR0
Intel Skylake and DDR4
3.
Remove the Top Covers
First, remove the middle cover:
Qty
1
1
Opt.
Opt.
Proceed to remove the motherboard cover:
2
Opt.
Opt.
1 set
2
1
4.
Inspect the Inside
comprise of a Gigabyte motherboard, an expander board,
optional rear 2x and 8x 2.5" bays, 3x internal 120mm fan
modules (electronically attached to the motherboard).
To install OS disk(s), a space for 2 OS disks is available on the
left inner wall of the chassis.
Observe ESD (Electrostatic Discharge) practices during integration to avoid
possible damage to the board and / or other components
of the unit as follows:
1. Push the latches inwards
2. Flip the cover outwards to remove
of the unit. Internal components
