Premio eDrawer4072S Quick Manual

1.
Check the content
package contains the following:
# Description Image / Description
eDrawer4072S
1
Enclosure
2 Motherboard
3 Heatsink
2.5" Drive Trays
4
(optional)
5 Power Cable*
6 Serial Cable*
7 Rail Kit
Cable
8 Management Arm
Kit
9 Chassis Handles*
10 SAS cables (opt.) SFF 8644-8644 / SFF 8088-8644
11 This Quick Guide
12 Packaging
* Inside the accessories box. If any items are missing, please contact
your authorized reseller or sales representative
2.
Get familiar with the unit.
eDrawer4072S is a 72-Bay storage server powered by Intel S2600TP
dual-processor E5 Haswell motherboard.
Front view of the unit
Top Cover for LP PCIe Gen3 x8 slot
Motherboard
Rack Screw
Hole
Latch for
MB Cover
Ear Handle
Motherboard
Front Panel
Reset Button
Drive Status LEDs
Power Button
for Bay 1-72
Drive Status LED:
(Solid) Drive Online (Solid) RAID Drive
(Blink) Drive Activity (Blink Purple on Solid Blue) RAID Activity / Rebuild
(Solid) Drive Fail (Alternating Blink) Drive Fault / RAID Failure
(Blink) Drive Missing (Blink) Drive Locate
Rear view of the unit
Handle for PS Handle for
Module Fan Module
Power Supply
Module 1
Power Switch
Fan 1
PSU Alarm
Mute Button
PSU Status
LED
Fan 2
AC Receptacle
Power Supply
Module 2
Installation and service of this product should be conducted by a trained
personnel to avoid bodily injury from electric shock or heavy object
eDrawer4072S Quick Guide
Version 2.20 – 2017.05.09
of the box. Please confirm that your
Qty
1
Intel S2600TP 1
2
8
2
1
2 sets
1 set
2
2
1
1 set
Top Cover for Drive Bay
Key Lock for Latch for Drive
the Latches Bay Cover
Drive Status LEDs for
8x 2.5" Rear Drive Bay
Drive Offline/ Removed
RAID Controller
Expander Board or HBA
Fan 3 Fan 5
8x 2.5" Bay
(optional)
Fan 4 Fan 6
Serial Port SAS Down Link Ports:
• Top for Bay 1-36
• Bottom for Bay 37-72
IO Panel
3.
Open the Drive Cover
1. Use the key to unlock the latch
2. Slide the right latch inwards
3. Unscrew the thumbscrews (red circles)
4. Lift the drive cover up
5. Support rod will slide to lock the cover open
4.
Open the Controller Cover
motherboard, fan modules, OS drives and IO cards:
5.
Inspect the Internal
Expander boards are located between drive slot and controller.
Riser Card for
Motherboard
IO Card
Front Expander
Drive Slots for
Front Bay 1 – 36
(3 rows of 12 drive slots)
Front expander controls the first front 36 disks, the rear expander
controls the last 36 disks. The internal RAID/HBA manages the drives for
the OS to see all 72 disks.
Above is the specification of the motherboard used for eDrawer4072S.
Observe ESD (Electrostatic Discharge) practices during integration to avoid
possible damage to the board and / or other components
of the unit reveals the drive slots.
as follows to reveal the
components under the hoods.
2x Drive Slots
Fan module
for OS disk(s)
Rear Expander
Drive Slots for
Rear Bay 37 – 72
(3 rows of 12 drive slots)
