Premio DSS424SF-D5 Quick Manual

Congratulation on your purchase of Premio DSS424SF-D5 Storage Server System!
1.
Check the Content
your package contains the following:
# Description
1 DSS424S-D5
Enclosure
2 Motherboard
3 CPU and memory
4 IO Cards
5 Heatsink
6 Slide Rail Kit + Screws
7 Power Cable*
8 Serial Cable*
* Inside the accessories box. Box may consist of screw sets for rail kit or
drives. If any items are missing, please contact your reseller or sales rep.
2.
Get Familiar with the Unit.
DSS424SF-D5 is a redundant server supporting dual Intel
processor with a front tray-less 24x 3.5" HDD storage, and
rear full-height IO cards in a 4U space. Two Tyan
motherboards (S7206GM2NR) and internal cabling are
preinstalled. IO cards, CPU, and memory are preinstalled
upon request.
Front View of the Unit
Rear View of the Unit
Installation and service of this product should be conducted by a trained
personnel to avoid bodily injury from electric shock or heavy object
DSS424SF-D5 Quick Guide
Version 1.00 – 2017.09.22
of the box. Please confirm that
Image / Description
Tyan S7206GM2NR
Intel Skylake and DDR4
3.
Install 3.5" Drives
suggested to install HDDs after the unit is mounted to the
Qty
rack.
1
2
Opt.
Opt.
2
1 set
2
1
4.
Remove the Controller Node
components required (IO cards, mezzanine, CPU, memory).
5.
Inspect the Controller Node
comprise of a Tyan motherboard, an expander board, IO card,
an NTB retimer board, NTB switch board, power board, 4x
internal fan modules (all connected to the motherboard).
6.
Install OS disk(s)
Observe ESD (Electrostatic Discharge) practices during integration to avoid
possible damage to the board and / or other components
to the unit as illustrated. It is
to install any
. The components
if required as follows:
