Premio OSS424S-D4 Quick Manual

Thank you for your purchase of Premio OSS424S-D4 Storage Server System!
1.

Check the Content

your package contains the following:
# Description
1 OSS424S-D4
Enclosure
2 Motherboard
3 CPU and memory
4 IO Cards
5 Heatsink
6 2x 2.5" Drive Bay
7 8x 2.5" Drive Bay
8 Slide Rail Kit + Screws
9 Power Cable*
10 Serial Cable*
* Inside the accessories box. Box may consist of screw sets for rail kit or
drives. If any items are missing, please contact your reseller or sales rep.
2.

Get Familiar with the Unit.

OSS424S-D4 is a storage server supporting dual Intel
processor and front tray-less 24x 3.5" HDDs, optional rear 2x
or 8x 2.5" drive bays powered by Asrock EP2C612D16C-4L
motherboard.
Front view of the unit
Rear view of the unit
Installation and service of this product should be conducted by a trained
personnel to avoid bodily injury from electric shock or heavy object
OSS424S-D4 Quick Guide
Version 2.10 – 2017.06.22
of the box. Please confirm that
Image / Description
Asrock DP motherboard
Intel E5 and DDR4
Qty
1
1
Opt.
Opt.
2
Opt.
3.
Opt.

Remove the Top Covers

First, remove the middle cover:
1 set
2
1
Proceed to remove the motherboard cover:
4.

Inspect the Inside

comprise of an Asrock motherboard, an expander board,
optional rear 2x and 8x 2.5" bays, 3x internal 120mm fan
modules (electronically attached to the motherboard).
To install OS disk(s), a space for 2 OS disks is available on the
left inner wall of the chassis.
Observe ESD (Electrostatic Discharge) practices during integration to avoid
possible damage to the board and / or other components
of the unit as follows:
1. Push the latches inwards
2. Flip the cover outwards to remove
of the unit. Internal components
