Table Of Contents - U-Line Echelon 2175R Installation Manual

Contents
Exterior Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cut-Out Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . .
Product Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Door Swing/Clearances Information . . . . . . . . . . . . . .
Reversing the Door. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Other Site Requirements . . . . . . . . . . . . . . . . . . . . . . . .
Side-By-Side Installation Instructions . . . . . . . . . . . . . .
Custom 1/4'' Door Panel Insert . . . . . . . . . . . . . . . . . . .
Full Overlay Door Panel . . . . . . . . . . . . . . . . . . . . . . . . .
Checking Door Alignment . . . . . . . . . . . . . . . . . . . . . . 12
Adjusting Door Alignment . . . . . . . . . . . . . . . . . . . . . . 12
Electrical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . 13
Leveling Information . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Installation Tip . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Installation of the 2175R/2175RF . . . . . . . . . . . . . . . . . 14
Relocating the Shelves . . . . . . . . . . . . . . . . . . . . . . . . . 14
Installation Troubleshooting . . . . . . . . . . . . . . . . . . . . . 14
Initial Start-Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Start-Up Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . 15
Service Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
www.U-LineService.com
2175R Refrigerator and 2175RF Refrigerator/Freezer
1 Follow Safety Precautions
4
4
5
PLEASE READ all instructions completely before
5
attempting to install or operate the unit.
5
6 • This unit requires connection to a grounded (three-
prong), polarized receptacle that has been placed by a
7
qualified electrician in accordance with applicable
7
electrical codes.
8
Safety Alert Definitions
Safety items throughout this guide are labeled with a
Danger, Warning or Caution based on the risk type:
Danger means that failure to follow this safety
statement will result in severe personal injury or
death.
Warning means that failure to follow this safety
statement could result in serious personal injury,
or death.
Caution means that failure to follow this safety statement
may result in minor or moderate personal injury, property
or equipment damage.
2
IMPORTANT
DANGER
WARNING
CAUTION
08/2006
