2175DWRR — Drawer Model Refrigerator 2 Inspect and Plan You have received a carton containing your 2175DWRR Drawer Model Refrigerator with a package inside containing a Use and Care Guide, a Product Registration Card and Anti-Tip Kit. Complete and mail the Product Registration Card or register online at www.U-LineService.com.
3 Prepare Site Your U-Line product has been designed for built-in installation. Your unit does not require additional air space for top, sides or rear. However, the front grille must NOT be obstructed and clearance is required for electrical connection in the rear.
Please note that the unit has adjustable feet that can add one additional inch to height during leveling or to match adjacent cabinets (see Figure 25 on Page 12). 06/2006 2175DWRR — Drawer Model Refrigerator Clearances Information The unit must be installed in a wall or under a counter- 25-13/16"...
60 Hz, 15A circuit (normal household current). See Electrical Specifications on Page 12. Environmental Requirements Many U-Line models are designed to operate in harsh outdoor/marine environments. Special considerations include the following: • The units are designed to operate between 50°F (10°C) and 110°F (40°C).
12-15/32" The door panels must not have a total weight of more than 20 lbs. 06/2006 2175DWRR — Drawer Model Refrigerator Drawer Panel Installation Install the insert as follows: Use care when handling the insert. Insert edges may be sharp.
2175DWRR — Drawer Model Refrigerator Full Overlay Drawer Panels Drawer Panel Preparation Full overlay drawer panels completely cover the drawer fronts and handles to give a built-in appearance. Black units are shipped ready for Full Overlay installation. Note: For standard installations, both drawers mount the same and a 1/2"...
3. Starting at the corners and working toward the center, push the drawer gasket back into place. Go on to 5 Adjust Drawers. 06/2006 2175DWRR — Drawer Model Refrigerator 5 Adjust Drawers Checking Drawer Alignment The unit’s drawers are aligned at the factory before shipment.
2175DWRR — Drawer Model Refrigerator Adjusting Drawer Alignment WARNING SHOCK HAZARD — The unit must be unplugged from the wall outlet during drawer removal, adjustment and re-installation. Drawer Removal 1. Confirm that the unit is unplugged from wall outlet. 2. Unplug the drawer’s connection wiring (top drawer only).
Page 11
Viewed from the top, one side will protrude. This is caused by one of the slides being mounted higher than the other slide on the unit’s liner. 06/2006 2175DWRR — Drawer Model Refrigerator Minor Adjustment: Note: The mounting holes Screws Should...
2175DWRR — Drawer Model Refrigerator 6 Prepare Power Supply Electrical Specifications CAUTION Electrical installation must observe all state and local codes. This unit requires connection to a grounded (three- prong), polarized receptacle that has been placed by a qualified electrician.
(three at each corner). Remove the appropriate screws for horizontal or vertical mounting (see Figure 26). Do not discard. 06/2006 2175DWRR — Drawer Model Refrigerator Horizontal Mounting (Left Side Shown) Vertical Mounting (Left Side Shown) Figure 26 2.
POWER icon (see Figure 27,1)on the display panel for aproximately ten seconds until the °F symbol flashes and release. All U-line units are shipped from the factory with controls that are preset. No initial adjustments are required. IMPORTANT...
See the Use and Care Guide’s Troubleshooting Guide for more solutions. For more than four decades, U-Line has distinguished itself as the leader in built-in undercounter ice making, refrigeration and wine storage appliances. U-Line Corporation, located in Milwaukee, WI, is a family operated manufacturer of built-in undercounter icemakers, Combo refrigerators, refrigerated drawers and refrigerator/freezers.
