Summary of Contents for Felix Storch Pro 3 L
- Page 1 Quick Start Guide FELIX Pro 3 L / XL www.FELIXprinters.com www.FELIXprinters.com support@felixprinters.com support@felixprinters.com Zeemanlaan 15 Zeemanlaan 15 3401MV IJsselstein 3401MV IJsselstein The Netherlands The Netherlands...
-
Page 2: Safety
Safety Ventilate General safety - Keep children under the age of 14 out of reach of the printer. Good ventilation while printing is advised. When printing ABS, small - FELIXprinters are only suitable for professional use. concentrations of styrene vapor can be released. This can (in some cases) cause headaches, fatigue, dizziness, confusion, drowsiness, malaise, Considerations when in operation. -
Page 3: Table Of Contents
Kind regards, FELIXprinters Contents Safety Introduction Contents Printer specifications FELIX Pro 3 L at a glance What´s in the box? Display Print proces simplified Preparation for printing Start a print Power loss recovery Printer calibration... -
Page 4: Printer Specifications
Printer specifications System specifications Interface - Printer dimensions (L, W, H) 600 x 666 x 776 mm (XL) - Capacitive Touchscreen, with embedded 1.2 Ghz - Printer dimensions (L, W, H) 906 x 666 x 966 mm (L) quad core processor. - Weight 65 kg (L), 80 kg (XL) - Print server (Repetier-Server) - Power requirements: 110 - 220 V... -
Page 5: Felix Pro 3 L At A Glance
FELIX Pro 3 L at a glance Display Enclosure Fan USB port Emergency stop Front door Side door Ethernet Power plug Power switch Page... -
Page 6: What´s In The Box
What´s in the box? 1x Tweezers 1x Spatula 1x Power cable 1x Allen key set 1x MicroSD card + USB reader 1x 1kg Premium PLA 2x Teflon tubes 1x Wrench 14mm Recommended tools: NB: The box could contain extra materials like filament you have ordered. Page... - Page 7 First Checks Place the printer on a sturdy surface and ensure the printer is “level”. Open the front door and place a bubble level on the center bottom or on the print-bed. Then level the printer, by adjusting the feet with the 14mm wrench. Open the top cover.
- Page 8 6.2 Opening/Closing the air vents The airvents on top of the printer are important: OPEN slots when using PLA, PETG, or TPU. CLOSE slots when using ABS, PC or Nylon Closing the slots retains more heat in the printer, which is beneficial for higher temperature materials as it reduces warping.
- Page 9 6.4 Power on Insert the power cable in the power socket Ethernet port Power switch Power socket Flip the power switch to the ON position Wait for the printer to turn on. The light of the print-head should light up immediately, the screen boots up in approximately 40 seconds.
-
Page 10: Display
Display Print files (G-codes ) USB Stick Change filament Move menu G-codes saved on the import gcodes Load & Unload Move the head or bed machine. from usb stick. filament. of the machine. Temperture Home Temperature graph of the Returns to home nozzle and buildplate menu. -
Page 11: Print Proces Simplified
Print proces simplified IMPORTANT! First Layer: Never leave printer unattended if you are not sure if first layer is printed correctly! 3D MODEL SLICE PRINT READY Follow the construction Choose correct settings accor- Make certain that the print surface is Allow the printer to per- rules of 3D printing (see ding to type of print object and... -
Page 12: Preparation For Printing
Preparation for printing Level the Buildplate IMPORTANT! At this stage, ONLY perform bed leveling as the printer is already factory calibrated. During this routine, the printer measures the build plate’s top surface to compensate for any irregularities, ensuring an optimal first layer. - Page 13 9.2 Clean the buildplate IMPORTANT: Detach the flexplate from the printer bed before cleaning the surface Foto buildplate met Foto loshalen flexplate flexplate The first layer is vital as it sets the foundation for the entire print. Follow these steps for a successful first layer: Remove any leftover filament from the print bed using a spatula or tweezers, being cautious not to damage the Kapton sticker.
- Page 14 9.3 Load Filament Open door Open door on either the left or right side door of the machine. on either the left or right side door of the machine. 2. 2. Place the filament spool Place the filament spool on the spool holders found inside. on the spool holders found inside.
- Page 15 When the filament exits the other end of the Bowden tube, guide it towards the printhead. Gently press on the hotend’s extruder to ease the pressure, facilitating smooth insertion. Slide the filament into the hotend until it reaches a stop. Foto insert filament in de printkop Foto indrukken hotend...
- Page 16 9.4 Change filament In the printer’s main menu, tap the “change filament” icon. In the subsequent menu, select either the left (extruder 1) or right (extruder 2) nozzle by tapping the blue top bar. After the nozzle heats up, the printer proceeds to the next menu where you can start by pressing “insert filament”.
-
Page 17: Start A Print
10 Start a print 10.1 Start a print using a USB stick Prepare and save a desired G-code which is generated with Simplify3D on a USB stick. Then plug the USB stick into the front USB port of the machine. Next, go to the printer’s main menu. In the main menu, tap the “USB Stick” button. If your Gcode file does not show up, tap the “Refresh”... - Page 18 10.2 Make connection through WI-FI You can link up to the printer either through Wireless LAN or a wired LAN connection. To get details about the connection, you'll need to navigate to the settings menu. In the settings menu, press the “Network” icon. A list of available networks will pop up.
- Page 19 10.3 Make connection through LAN Insert an Ethernet cable at the back of the printer. Make sure you're connected to the same network; if not, you won't be able to access the printer. Go to the settings menu and press the Network button to find the IP address. 10.4 Remotely control the printer via WI-FI or LAN Once you've set up a WiFi or wired connection with the printer, go to Settings ->...
- Page 20 10.5 Print via web interface. Overview of the dashboard. Press the “Go to Printer” button. Page...
- Page 21 1. Press Upload G-Code, to upload a g-co- de for printing to the library After Uploading, the touchscreen will render an image for printing 2. Press the print icon, the print will start. 10.6 Webcam monitoring You can easily keep an eye on a printing job using the webcam. Currently, this feature is only accessible within the internal net- work.
-
Page 22: Power Loss Recovery
11 Power loss recovery The FELIX Pro L and XL 3.0 feature a power loss recovery system that helps safe prints due to power failure or blackouts. The printer has entered rescue mode if you see the message below. In case of a powerloss, press “Rescue print” and only continue the print if the following is true: •... -
Page 23: Printer Calibration
12 Printer calibration The first layer of a print is vital as it sets the foundation for the entire print. To ensure optimal operation and reduce chances of failure there are automated calibrations in place. The calibration process relies on several key printer features: •... - Page 24 12.2 Bed leveling calibration To make sure the distance between the bed and the nozzles is consistent across the entire build plate, you need to perform a bed leveling sequence. When to do this calibration? • When changing to a new bed. •...
- Page 25 Once you’ve completed the bed leveling sequence, it’s important to check if the calibration was successful. The most effective way to test if the bed is level is to print “bed leveling squares,” allowing you to examine the first layer closely. It's too far, bring it closer.
- Page 26 12.3 Potential errors The printer uses a probe sensor in the extruder to detect the build plate. While doing this, the probe of the left or right hot-end is monitored. If one of the two cause an issue, you might see an error message saying "bed leveling failed" or "G33 leveling failed." If this happens, first ensure the machine homes all its axes.
- Page 27 12.4 Detecting the height difference between hot-ends. The print-heads when activated it needs to work at the same height. Due to production tolerances the hot-ends are normally slightly different in length. This difference must be calibrated. When to do this calibration? •...
- Page 28 12.6 Z-Calibration Z calibration includes using probes on both heads to determine the level of both extruders. This is really important to prevent crashes and ensure successful dual or multi-material printing. To begin this process, follow the instructions provided below. After this the machine will heat up and begin probing the heads and comparing the results.
-
Page 29: Tips And Tricks
13 Tips and Tricks 13.1 Flexible filaments (TPU) Flexible filaments when handled with care will print well. Depending on the amount of flexibility and elasticity, you might need to take some extra precautions to print it without trouble. Precautions Ensure you use the correct slicing profiles for flexible filaments from our supported software. Ensure the extruders are cleared from non-flexible filaments. -
Page 30: Maintanence
14 Maintanence The printer features a comprehensive and intricate motion system, which requires regular maintenance and care to ensure opti- mal performance. 14.1 Hot-end Maintanence For cleaning or maintenance purposes, the hot-end can be easily removed from the FELIX Pro L/XL. Please take the following steps. - Page 31 14.2 Removing the Hot-end Gently detach the edge connector from the corresponding print head. Avoid tugging on the wires; instead, grasp and remove the plug itself. Additionally, take note of the small hook located on the fan duct designed to guide the cables. Be aware that this hook is stationary, and the cables must be released before proceeding to remove the hotend.
- Page 32 14.3 Replace dust cleaners Filament tends to accumulate a significant amount of dust and tiny particles. Ensure that the filament is guided into the filament holder using the dust cleaner. It is advisable to replace the dust cleaners after a few months of continuous printing. 14.4 Motion System The linear bearings require minimal maintenance.
-
Page 33: Display Messages
15 Display Messages Firmware requested pause/filament jam detected The flow detection system is triggered – the printer moves to its idle position waiting for user action. The flow detection system is triggered when there is no more filament going through the extruder or when the filament is not extruding at the expected rate. - Page 34 Review our products Help us to improve our products and services. It only takes a few minutes! www.felixprinters.com/survey (a small reward is waiting for you) FELIX Community Manuals & tutorials www.felixprinters.com/community www.felixprinters.com/support Page...
- Page 35 www.felixprinters.com support@felixprinters.com Zeemanlaan 15 3401MV IJsselstein The Netherlands V8.3 - 2023 - MB...
