Summary of Contents for Felix Storch Pro 3
- Page 1 Assembly Manual – Cover Unit 6 September FELIX Pro 3 2019 Revision 1...
-
Page 2: Table Of Contents
1 Introduction Thank you for choosing FELIXprinters! This manual describes how to assemble the FELIX Pro 3 Cover unit. This cover unit is also compatible with the FELIX Pro 1 and 2 If you are unable to continue or have any questions, you can check at the support section of our website or you can... -
Page 3: Bill Of Materials
Door Panel Housing - Pro 3 - 03210_0 130 218.0 Front Left_Right Housing - Pro 3 - 03211_0 130 219.0 Bottom Front Housing - Pro 3 - 03212_0 130 220.0 Front Top Panel Housing - Pro 3 - 03213_0 www.FELIXprinters.com FELIX Pro 3... - Page 4 Bill of materials Assembly Manual – Cover Unit 6 September 2019 130 221.0 Back Left_Right Panel Housing - Pro 3 - 03214_0 130 222.0 Back Bottom Panel Housing - Pro 3 - 03215_0 130 223.0 Back Top Panel Housing - Pro 3 - 03216_0 130 224.0...
-
Page 5: Front Side
Front Side Assembly Manual – Cover Unit 6 September 2019 4 Front Side Create front side subassembly first. Below an overview. Corner Middle piece www.FELIXprinters.com FELIX Pro 3... -
Page 6: Corner Detail
Put corners together with the corner piece and 3 times an M4x10 hexagon socket head screw. Mid-bracket detail Fix plates together with the middle brackets. Each bracket requires 2 times an M4x10 hexagon socket head screw. www.FELIXprinters.com FELIX Pro 3... -
Page 7: Hinge Detail
Fix the 2 hinges on the front panel and the door, by using M5x8 hexagon socket head screws. Door handle detail M3x4 button head Magnet Backside of door handle. Fix magnet with Fix the door handle on the door panel, m3x4 button head screw with 2x m4x10 hexagon socket head bolts www.FELIXprinters.com FELIX Pro 3... -
Page 8: Back Side
Back Side Assembly Manual – Cover Unit 6 September 2019 5 Back Side Now create back side subassembly in the same fashion as the front side. Corner Middle piece www.FELIXprinters.com FELIX Pro 3... -
Page 9: Mount Subassemblies To Printer
Assembly Manual – Cover Unit 6 September 2019 6 Mount subassemblies to printer Slide in t-slot nuts into frame Push and turn t-slot nut into frame. Place t-slot nuts on following places for the following places: www.FELIXprinters.com FELIX Pro 3... -
Page 10: September
Mount subassemblies to printer Assembly Manual – Cover Unit 6 September 2019 Place cover assemblies onto frame and fix them with the M4x10 socket head screw. Congratulations, you’ve finished assembling the cover unit. www.FELIXprinters.com FELIX Pro 3...
