How to check Pro L/XL internal probe cables
10 May 2022
FELIX Pro L and XL
Revision 0
series

Advertisement

loading
Need help?

Need help?

Do you have a question about the Pro L Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Felix Storch Pro L Series

Summary of Contents for Felix Storch Pro L Series

  • Page 1 How to check Pro L/XL internal probe cables 10 May 2022 FELIX Pro L and XL Revision 0 series...
  • Page 2 Pro L XL series How to check Pro L/XL internal probe cables May 10, 2022 1 Introduction This manual explains how to disassemble and assemble the printhead for an Pro L/XL to check the internal probe cables. Only follow this guide if someone from FELIXprinters has told you to 2 Tools The tools you need: •...
  • Page 3 Pro L XL series How to check Pro L/XL internal probe cables May 10, 2022 2) Remove the 2 top bolts Remove the 2 bolts using an allen key 2,5. Red circles. 3) Remove the side bolt Remove the bolt that holds the 2 printhead assemblies together using an allen key 3. circle.
  • Page 4 Pro L XL series How to check Pro L/XL internal probe cables May 10, 2022 4) Take off the printhead Carefully take off the left printhead. Watch out because the head is connected to the PCB with cables. 5) Remove the servo Remove the buttonhead bold that holds the servo.
  • Page 5 Pro L XL series How to check Pro L/XL internal probe cables May 10, 2022 6) Check probe cable connections Check the probe cable connection behind the servo. Tighten them and make sure the 2 ayes don’t touch each other, and touch the magnets properly. Keep in mind that they are from plastic.
  • Page 6 Pro L XL series How to check Pro L/XL internal probe cables May 10, 2022 8) Check tight printhead probe connections Check the probe cable connection from the right extruder. Tighten them and make sure the 2 ayes don’t touch each other, and touch the magnets properly. Keep in mind that they are from plastic.
  • Page 7 Pro L XL series How to check Pro L/XL internal probe cables May 10, 2022 4 Assemble printhead 1) Place back the printhead When slicing the printhead on the bracket make sure no cables get stuck. circle. 2) Place the right printhead Start with sliding the left printhead on the bracket.
  • Page 8 Pro L XL series How to check Pro L/XL internal probe cables May 10, 2022 3) Screw the side bolt Tighten the bolt that holds the 2 printhead assemblies together using an allen key 3. circle. 4) Place the 2 top bolts Place and tighten the 2 bolts using an allen key 2,5.

  • Page 9: Printer Check

    Pro L XL series How to check Pro L/XL internal probe cables May 10, 2022 5 Printer check 1) Temperatures Info: reinstall the ribbon cables into the connector if it doesn’t! Check if the printer can read the hotend temperatures. 2) Probe check Press “Advanced”.
  • Page 10 Pro L XL series How to check Pro L/XL internal probe cables May 10, 2022 Press “Console”. Press “Send G-code”. www.FELIXprinters.com FELIX Pro L XL...
  • Page 11 Pro L XL series How to check Pro L/XL internal probe cables May 10, 2022 Type in “M119” and send it to the printer. Look in the console. If the “Z-probe state” is “L” (Low) you can proceed in the manual and try to home.
  • Page 12 Pro L XL series How to check Pro L/XL internal probe cables May 10, 2022 3) Homing Press “move”. Hit “home all”. If it doesn’t home correctly. Turn off the printer and contact Support@felixprinters.com. www.FELIXprinters.com FELIX Pro L XL...
  • Page 13 Pro L XL series How to check Pro L/XL internal probe cables May 10, 2022 6 Levelling Info: Do all calibrations before staring a Dual head print! 1) Build plate leveling Press “printer calibration”. Press “bed leveling”. www.FELIXprinters.com FELIX Pro L XL...
  • Page 14 Pro L XL series How to check Pro L/XL internal probe cables May 10, 2022 Hit “yes” to start the bed leveling. The bed leveling is done when you see this message. Hit “ok”. www.FELIXprinters.com FELIX Pro L XL...
  • Page 15 Pro L XL series How to check Pro L/XL internal probe cables May 10, 2022 2) Z-calibration Press “printer calibration”. Press “Calibrate Z”. www.FELIXprinters.com FELIX Pro L XL...
  • Page 16 Pro L XL series How to check Pro L/XL internal probe cables May 10, 2022 Press “Yes”. Press “Ok”. www.FELIXprinters.com FELIX Pro L XL...
  • Page 17 Pro L XL series How to check Pro L/XL internal probe cables May 10, 2022 3) XY-calibration Press “printer calibration”. Press “Calibrate XY”. www.FELIXprinters.com FELIX Pro L XL...
  • Page 18 Pro L XL series How to check Pro L/XL internal probe cables May 10, 2022 Load in PLA in both hotends and hit “Yes”. Make sure line 5 matches both nozzles for the X and Y. Does it not? then enter the number where the lines do match and start the calibration again.
  • Page 19 Pro L XL series How to check Pro L/XL internal probe cables May 10, 2022 If you are unable to continue or have any questions, you can check at the support section of our website or you can contact us directly: Website: www.felixprinters.com/support Email:...
