Dynamic Water Pressure
Max: 5.0 bar
Min: 0.2 bar
2.0
3.0
1.0
4.0
0
5.0
Pressure
BAR
Maximum Static Pressure: 10.0 bar
Pack Contents
Single
Function
Handset
Handset Holder
x1
x2
Rubber
Washers
Metal
x2
Backnuts
x2
Plinths
Rubber
x2
Washers
All products manufactured and supplied by Bristan are safe to use provided that they are installed, operated and
receive regular maintenance in accordance with these instructions.
This product needs to be installed in accordance with, and meet the requirements of The Water Supply (Water
Fittings) Regulations (Northern Ireland) 2009 and The Water Supply (Water Fittings) (Scotland) Byelaws 2014.
For full Installation Requirements & Notes (IRN) please visit www.wrasapprovals.co.uk/approvals-directory
Isolation valves must be fitted to the inlet water supplies to ensure ease of future maintenance.
Before installing this product the water supply must be thoroughly flushed in order to remove any swarf, solder etc.
Full access must be made available for future maintenance/servicing purposes.
This product must not be modified in any way as this will invalidate the guarantee.
Specifications
Inlet Water Temperature
Maximum Hot 60°C
IMPORTANT
x1
The diverter cannot
be maintained on
this model. If you
have any issues
please contact
Customer Services
on 0330 026 6273.
x1
Tap Body
x1
Cone
Tools Required for Installation/ Maintenance
to
Nut
Hose
Prior to Installation
Installation Instructions
Please leave these instructions
Inlet Connections
60°C
HOT
ON
32mm
17mm Socket
Adjustable
Box Spanner
Spanner
Spanner
& User Guide
with the end user
3/4" BSP
Operation
COLD
Pull Up for
Handset
2mm
Crosshead
Pipe
Cutters
Hex Key
Screwdriver
MIO BSM C (D1)
Outlet Connections
M24 Flow
Straightener
ON
Drill
Safety
Goggles
Spare Parts
To replace any spare parts
for your tap, why not
scan the QR Code or
visit www.bristan.com
and search for your
product.
