Bristan MIO BAS C (D1) Installation Instructions & User Manual

Dynamic Water Pressure
Max: 5.0 bar
Min: 0.2 bar
2.0 3.0
1.0
4.0
0 5.0
Pressure
BAR
Maximum Static Pressure: 10.0 bar

Pack Contents

Tap Body
x1
Plinth
x1
Fixing Kit
x1
All products manufactured and supplied by Bristan are safe to use provided that they are installed, operated and
receive regular maintenance in accordance with these instructions.
This product needs to be installed in accordance with, and meet the requirements of The Water Supply (Water
Fittings) Regulations (Northern Ireland) 2009 and The Water Supply (Water Fittings) (Scotland) Byelaws 2014.
For full Installation Requirements & Notes (IRN) please visit www.wrasapprovals.co.uk/approvals-directory
Isolation valves must be fitted to the inlet water supplies to ensure ease of future maintenance.
Before installing this product the water supply must be thoroughly flushed in order to remove any swarf, solder etc.
Full access must be made available for future maintenance/servicing purposes.
This product must not be modified in any way as this will invalidate the guarantee.

Specifications

Inlet Water Temperature
Maximum Hot 60°C
x2
Flexible
Tails

Tools Required for Installation/ Maintenance

x1
Rubber
Washer

Prior to Installation

Installation Instructions
Please leave these instructions
Inlet Connections
60°C
1/2" Flexible Tails

Operation

Box Spanner Socket
Adjustable
Spanner Spanner
& User Guide
with the end user
MIO BAS C (D1)
Outlet Connections
Straightener
ON
HOT
2.5mm Hex
Pipe
Cutters Key

Spare Parts

To replace any spare parts
for your tap, why not
scan the QR Code or
visit www.bristan.com
and search for your
M24 Flow
COLD
Crosshead
Screwdriver
product.
